Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > ZP-33D Rotary Type Tablet Pressing Machine

ZP-33D Rotary Type Tablet Pressing Machine

Name: ZP-33D Rotary Type Tablet Pressing Machine
Brand: LTPM CHINA
SKU: 132953883
Availability: InStock

ZP-33D Rotary Type Tablet Pressing Machine thumbnail-1

ZP-33D Rotary Type Tablet Pressing Machine photo-1

US$ 4,000 - 16,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

LTPM CHINA

Contact Supplier Request Quote Chat Now

Ruian City LeadTop Imp& Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Port or Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name LTPM CHINA

Model Number ZP-33D

Type Rotary Tablet Press

Production Capacity 75000Tablets/hour

Max. Pressure(KN) 80KN

Max. Tablet Thickness(mm) 9mm

Max. Tablet Diameter(mm) 25mm

Voltage 380V 50Hz three phase

Power(W) 6Kw

Weight 350Kg

Dimension(L*W*H) 1010*1010*1820mm

Certification CE,SGS,ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Rotary Tablet Press Machine passed CE Cert
2.GMP Model with whole body stainless steel
3.Multi function Tableting Machine

ZP-33D Rotary Tablet Pressing Machine

Application:
That machine is a double press automatic rotation can be equipped with force-feeding system for shape-pressing equipment, which have the function of press the grains material to be round or irregular shape tablets, such as candy, calcium tablets double-sides with letter printing and etc. which widely suitable for the Industries of pharmaceutical, Chemical, Foodstuff, Plastic Electronic, Powder Metallurgy and so on.
Features:
1. The material of the machine is made of stainless steel with totally closed, the surface of turntable deal with polished and prevent cross pollution which meet the GMP standard. 2. It is equipped with Organic-glass perspective window for tablet producing observation. Each perspective window could be fully opened and easy for cleaning and maintenance. 3. It is adopts the import Frequency Timing with Electromagnetism Clutch. 4. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance. 5. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust *Main Technical Data:*
Stations (unit)	33	Thickness of the die (mm)	28
Maximum compression (KN)	80	The diameter of the circle of the central pitch of upper &lower punches on the turret	320mm
Max. Diameter of tablet to be produced (mm)	25	Rotary speed of the turret (rpm)	10-25
Max. Filling depth (mm)	22	Capacity of the tablets (tablets/hour)	75,000
Max. Thickness of tablet (mm)	9	Area to occupy (mm 2 )	1010*1010
Diameter of the upper/lower shank (mm)	32	Height of the machine (mm)	1550
Length of the upper shank (mm)	175	motor power (kw)	6
Length of the lower shank (mm)	183	Net weight of the machine (kg)	1.8
Diameter of the die (mm)	36
