BG-80 High Efficiency Tablet Film Coating Machine

BG-80 High Efficiency Tablet Film Coating Machine thumbnail-1
BG-80 High Efficiency Tablet Film Coating Machine photo-1
US$ 25,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
LTPM CHINA
Contact Supplier Request Quote Chat Now
Ruian City LeadTop Imp& Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo City or Shanghai City
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name LTPM CHINA
Model Number BG-80
Usage Other, Pharmaceutical, Tablet Coating
Voltage 380V 50Hz three phase(optional)
Power(W) 5.6Kw
Weight 1200Kg
Dimension(L*W*H) 1370*1030*1950mm
Certification CE,SGS,ISO
Warranty 1year
After-sales Service Provided Engineers available to service machinery overseas

BG-80 Film Coating Machine

Simple Instruction

       The machine can be used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film, etc. And it has such characteristics as high efficiency, low energy consumption and small floor area, etc. And it can be widely used for coating various tablets, pills and sweets with organic film, water-soluble film and sugar film etc. In such fields as of pharmaceutical, food and biological products etc.

       And it has such characteristics as good appearance in design ,high efficiency, low energy consumption and small floor area, etc.

       This machine is made of high-quality stainless steel elaborately and meets the The tablets make complicated and constant track movement with easy and smooth turning and frequent exchanging in the clean and closed rotational cylinder of the film coating machine. And it can automatically spray coating medium according to the process flow and reasonable process parameters. The hot air exhausted through the bottom of the tablets under the effect of air exhaust and negative pressure so as to make coating medium dry quickly on the surfaces of the tablets and form a firm, fine and close and smooth surface film.

Performance and Feature

  • With PLC module, all operations such as hot air temperature setting and control, revolutions of the drum adjustment, automatic control and display of negative pressure etc can be in run by pushing the touch key on the computer-controlled panel fully sealed with slight touch film interface.
  • The machine is free to clean, with such characteristics as reliable and stable performance.
  • The streamline guiding-type mixer drives tablets to make easy and smooth rotation without fragment and chipped edge, which improves the yield.
  • The guiding sheet has a narrow surface, to which no dressing can be stuck, economization on dressing and improving the quality of finished products.
  • The constant-pressure variable crawler pump features the revolution radius of the roller subject to pressure, automatic control of output syrup amounts and sprayed syrup amounts, stabilization of atomization, simplify of spraying system, economization on dressing, easy to fully clean.
  • The specially designed imported s pray gun features east to operate and control technological requirements, uniform density and particle size, uniform atomization and large spray area, practical to adjust flow, free leakage and blockage, angle and sector.
  • The gun can be in operation until its head keeps in the range of 0.29Mpa to 0.39Mpa. Until now, It has been favorably reviewed from users at home and abroad.

Main Technical Data:

Items Model

BG-80

Max. tablet volume

80kg/batch

Sugar coating drum dia.

F930mm

Feed inlet dia

F380mm

Sugar coating drum speed

0-19 r.p.m

Host machine motor power

1.5 kw

Exhaust cabinet motor power

3 kw

Exhaust blower air flow

5268 m3/h

Hot air cabinet motor power

1.1 kw

Air heater air flow

1685 m3/h

Air heater temp.-adjust range

~ 80 °C

Hot air cleanness

100000 level

Peristaltic pump or lobe pump motor power

0.37kw (0.55kw)

Silicon rubber hose

F 9~16mm

External dimensions of host machine

1370*1030*1950

mm

Host machine weight

600kg

External dimensions of hot air cabinet

900x800x2170

mm

Hot air cabinet weight

450kg

External dimensions of exhaust cabinet

1110x820x2000

mm

Exhaust cabinet weight

500kg

External condition



Clean

Air

Pressure

³0.4Mpa

Air consumption.

0.7m3 /min.

Water

source

Pressure

³0.15Mpa

Pipe diameter

1’’

Steam

heating

type

Steam

Pressure

³0.4Mpa

Air consumption.

80kg/h

Power source

3 phase and 5 lines

6 kw

Electric heating type

Power source

3 phase and 5 lines 32 kw



BG-80 High Efficiency Tablet Film Coating MachineBG-80 High Efficiency Tablet Film Coating Machine



Packaging and Shipping:

BG-80 High Efficiency Tablet Film Coating Machine

BG-80 High Efficiency Tablet Film Coating Machine





For more informations, please contact us by mail or make a call. You are the most welcome here.

LTPM CHINA, Your Best Pharmaceutical Production Solution!
