Specifications
Movable shaft tension sensor
1.High accuracy
2.Easy to install
3.Wholesale price
4.Fast delivery.
Movable shaft tension sensor
Features & Applications:
FLANGE Tension sensor design in movable shaft structure, in the production process of ontinuous material, it is easy to replace the tension measuring roll. It can be mounted on the side of equipment with bolt, it can also be installed in the top of the device through the mounting bracket matching. Electrical connector surface sensor has a red dot indicating the positive direction of sensor axis. Even wrap angle of the material is smaller, it also can ensure the accurate measurement of tension when the dead-weight of tension measuring roll is big.
Technical features:
10 times overload capacity, zero point stability, no need to re-calibrate the sensor.
20:1 force measurement range, within the force measuring range, the accuracy can be 0.5%
The rated range 250, 500, 1000N, suitable for application widely
Sensor is made of stainless steel, corrosion resistance, high reliability
Capacity: 250N 500N 1000N
Specification
| Rated Output | 1.5 ± 2.0% mV / V |
| Non-linearity | ≤ 0.02~0.05 % F.S. |
| Hysteresis | ≤ 0.02~0.05 % F.S. |
| Creep(30min) | ≤ 0.03 % F.S |
| Repeatability | ≤ 0.02~0.05 % F.S. |
| Temperature Effect On Output | ≤ ± 0.03% F.S. / 10ºC |
| Temperature Effect On Zero | ≤ ± 0.03 % F.S. / 10ºC |
| Input Impedance | 380 ± 2Ω |
| Output impedance | 350 ± 2Ω |
| Insulation | ≥ 5000MΩ/50VDC |
| Recommended Excitation | 12V |
| Maximum excitation | 10~15 V |
| Operation Temperature Range | - 20 ~ 70 ºC |
| Safe Overload | 1000 % F.S. |
| Standard signal output throug amplifier | (0-5)v,(0-10)v,(4-20)mA optional |
| Material | Stainless steel |
| Cable Color Code |
Input: Red(+) Green(-); Output: Yellow(+) White(-); |
