Galvanized Flat Bar

Specifications

Galvanized steel flat bars
1.thickness:1.5-14mm
2.width:10-1010mm
3.length:5.8m ;6m; 9m; 12m etc...



steel flat bar grade: A36, S235jr, St37-2, SS400, Q235, Q195

steel flat bar standard: ASTM, AISI, EN, DIN, JIS, GB

steel flat bar thickness:1.5mm-14mm   steel flat bar width: 10mm-1010mm

steel flat bar length: 5.8m, 6.0m;9m, 12m or as your requirement.

steel flat bar technique: slitting hot rolled steel coil

Place of origin: Tianjin China (Mainland)

Products Advantages: 1. high quality

                                   2. high dimensional accuracy

                                   3. high utilization rate of material

                                   4. saving cost price

General specification below:

Steel Flat Bar
Width (mm)	Thickness (mm)	Length (m)	Theoretical Weight         (kg/m)
20	2.0	6/9/12	0.31
20	2.5	6/9/12	0.39
20	2.75	6/9/12	0.43
25	2.5	6/9/12	0.49
25	3.75	6/9/12	0.74
30	2.5	6/9/12	0.59
30	3.5	6/9/12	0.82
30	9.75	6/9/12	2.30
40	3.5	6/9/12	1.10
40	4.75	6/9/12	1.50
40	11.75	6/9/12	3.69
50	2.75	6/9/12	1.08
50	4.5	6/9/12	1.77
50	9.75	6/9/12	3.83
60	5.5	6/9/12	2.60
60	7.5	6/9/12	3.53
60	11.5	6/9/12	5.42
80	5.5	6/9/12	3.45
80	7.5	6/9/12	4.71
80	11.75	6/9/12	7.38
100	3.25	6/9/12	2.55
100	4.75	6/9/12	3.73
100	7.5	6/9/12	5.89
120	9.75	6/9/12	9.18
120	11.75	6/9/12	11.07
150	9.75	6/9/12	11.48
150	11.5	6/9/12	13.54
150	13.5	6/9/12	15.90
160	11.75	6/9/12	14.76
200	9.5	6/9/12	14.92
250	5.75	6/9/12	11.28
340	7.75	6/9/12	20.68
