VCAN1139 Home DVB-T Digtal TV Receiver

Name: VCAN1139 Home DVB-T Digtal TV Receiver
Brand: VCAN
SKU: 132870377

US$ 14.8 - 14.8 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VCAN

Model Number:

VCAN1139

Vcan Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VCAN

Model Number VCAN1139

Product Description

VCAN1139 Home DVB-T Digtal TV Receiver

Selling Points:

Fully comply with DVB-T/T2 and H.264,

MPEG-4, MPEG-2 Standard

Support 3D interface

Powerful and highly effective 7-day EPG function

USB 2.0 for PVR,TIMESHIFT,

software upgrade and media files playback

Sortware Features
•Fully comply with DVB-T/T2 and H.264, MPEG-4, MPEG-2 Standard
•The maximum speed of the traffic flow of at least 50 Mbit / sec
•Support 3D interface
•Sleep Timer
•Support teletext/subtitle/muti-language
•Powerful and highly effective 7-day EPG function
•AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3 Pan G Scan, 4:3 Full, 16:9 Wide Screen
•USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback
•Video output resolution: 480i/576i/480p/576p/720p/1080i/1080P
Decoder
Video Decoder	Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818 MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps) MPEG-2 Main Profile# Main Level(15Mbps) H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps)
Powerful Multimedia Features
MediaCodec	avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc
Audio Codec	WMA,MP3,AAC (.wma,.mp3,m4a)
Photo Codec	JPEG, BMP, PNG

Hardware
CPU	MSTAR-MSD7T01(128 pin) MIPS 34Kf@600MHz
Memory	MSTAR-MSD7T01 implant 32X16Mbit DDR2 Frequency1066
Flash	32M bytes
Demodulator Type	MSTAR-MSD7T01 implant
TUNER	Rafael R836
Front Panel	USB 2.0 Embedded One Host,
	4-digit LED display on front panel
	red LED Standby,green LED Lock
	Panel KEY, POWER, CH+ ,CH-
Rear Panel	Tuner RF input connector	IEC-162-2( Female)
	Tuner RF Loop through connector	IEC-162-2( Male)
	HDMI V1.3/V1.4
	RCA CVBS AL AR Connector x1
	Ypbpr RCAx1
	Coaxial x1
	Power AC100~240V 50Hz/60Hz
Demodulation
Terrisal Receiver Standard	DVB-T2/T(EN_302755 V1.3.1/EN 300744)
Input RF Frequency	48~866MHZ
Bandwidth	6MHz,7MHz,8MHz
Constellation	QPSK 16-QAM 64-QAM and 256-QAM
FEC	1/2, 3/5,2/3, 3/4,4/5,5/6
Guard Interval	1/128 1/32 1/16 19/256 1/8 19/128 1/4
FFT Mode	2K/ 8K/32K
Support	Support Single and multiple PLPS
Input level	-83 - -5dBm
