VCAN0328 15" VGA USB POS Touchscreen TFT LCD Rear View Monitor

VCAN0328 15" VGA USB POS Touchscreen TFT LCD Rear View Monitor thumbnail-1
VCAN0328 15" VGA USB POS Touchscreen TFT LCD Rear View Monitor photo-1
US$ 88 - 110 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Screen Size:
Other, 15"
Contact Supplier Request Quote Chat Now
Vcan Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Desktop
Screen Size Other, 15"
Response Time 8ms
Brightness 400cd/m
Interface Type D-Sub, RS232C, TV-out
Contrast Ratio 700:1
Resolution 1024 x 768
Widescreen Yes
Panel Type TFT
Pixel Pitch 0.107 (W) X 0.372(H) mm
Brand Name VCAN
Model Number VCAN0328
Place of Origin Guangdong, China

Specifications

1 TFT LCD Monitor
2 Car use, POS use, Rear view Monitor
3 Touchscreen
4 Operating All Systems
5 MOQ: 2 PCS

VCAN0328 15" VGA  USB POS Touchscreen TFT LCD Rear View Monitor



VCAN0328 Features:



  TFT MONITOR

One of the world's most high-precision four wires resistive type touch-screen for PC display. (USB port/COM RS232 optional)

Sensitive touch-screen, quick response

Standard VGA (15 pin D-SUB RGB) and Two RCA/BNC video input
Built-in speaker amplifier/PC audio input and earphone jack
Operating All Systems: DOS/Windows  9X ME 2K XP  7 Vista  NT  CE / LINUX / Mac,etc.

Can support almost all kinds of resolution

Low radiation and consumption. High reliability, good stability, especially for work in harsh environments.



VCAN0328  specifications:



TFT MONITOR

  • Panel: 15" A+ GRADE Panel
  •
  • Display Type: 4:3 /16:9Ratio
  •
  • Physical Resolution :1024X768
  •
  • 4- wires /5-wire resitive touch-screen  optional.
  •
  • Touchscreen Interface: Serial (RS232) or USB optional.
  •
  • 15 pin D-SUB VGA signal input.
  •
  • SD/USB card reader  and TV/AV fucntion is optional.
  •
  • Built in Speaker.
  •
  • OSD: Remote control OSD(Voice, Brightness, Contrast)
  •
  • One VGA input, 2 AV Input, 1 AV Input
  •
  • Input Video Format:  Analog RGB ,NTSC/PAL/SCAME(AUTO)
  •
  • Touchscreen Interface: Serial (RS232) or USB
  •
  • Operating System:  DOS/Window  9X  ME,  2K  XP  Vista  NT Windows CE / LINUX / Mac
  •
  • Power Consumption: <30 W Typ
  •
  • Working Vplt:11V-15V



 Technical Specification:



  • Touch Response Time Serial/USB: 10.4ms
  •
  • PowerSupply: 85-265VAC,50-60HZ
  •
  • Pixel Pitch: 0.107 (W) X 0.372(H) mm
  •
  • Pixel Response Time Rise + Fall (Typically): 8ms
  •
  • Brightness: 400 cd/m2
  •
  • Contrast: 700:1
  •
  • ViewingAngle Horizontal (left/right): 170° (85°/85°)
  •
  •  (From Centre, CR>=5) Vertical (up/down): 160° (70°/90°)
  •
  • Temperature Range: Operating:-20°C-60°C,
  •
  • Storage:-30°C-70°C
  •
  • Relative Humidity Non Condensing:  Operating:10%-90%, Storage 5%-90%
VCAN0328 Pictures:

VCAN0328 15" VGA USB POS Touchscreen TFT LCD Rear View Monitor
