Home > Products > Channel letter laser machine > Multi-function automatic CO2 metal laser cutting machine
Multi-function automatic CO2 metal laser cutting machine
- 200 Set / Sets per Month
- qingdao shanghai guangzhou
- T/T Credit Card PayPal
Product Details
Condition: | New | Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Glass, Leather, Metal, Paper, plastic, Plywood, Stone, Wood |
Cutting Thickness: | according to different materials | Cutting Area: | 1200*2500mm, 1200*2500MM | Cutting Speed: | 20m/min |
CNC or Not: | Yes | Cooling Mode: | Other, Thermostatic cooling industrial refrigeration systems | Control Software: | Cypcut |
Graphic Format Supported: | AI, DST, DWG, DXF, DXP, LAS, PLT | Brand Name: | Datron | Model Number: | L2 - 1325 |
Certification: | CE, ISO, SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Multi-function Automatic CO2 3d Metal Laser Cutting Machine
Product Specifications For Automatic CO2 Metal Laser Cutting Machine
Technical Parameters | L2-1325 | L2-1530 | L2-2030 |
Cutting Area | 1200*2500 | 1500*3000 | 2000*3000 |
Size(L,W,H) | 1950*3650*1300 | 2250*4150*1300 | 2650*4150*1300 |
Location Precision | 0.05mm/m | 0.05mm/m | 0.05mm/m |
Location Speed | 20m/min | 20m/min | 20m/min |
Weight | 900kg | 1300kg | 1500kg |
Electric Power Demand | 220v/20A | 220v/20A | 220v/20A |
Cutting parameters For Automatic CO2 3d Metal Laser Cutting Machine
Cutting parameters | 150W | 260W | 320W |
Material thickness | M/Min |
|
|
1MM Stainless steel | 2.7-3 | 3.3-3.6 | 5 |
1.2MM Stainless steel | 1.5-1.8 | 2.5-3 | 4 |
2.2MM Stainless steel |
| 1.8 | 2.5 |
2.5MM Stainless steel |
|
| 1.2 |
1MM Carbon steel | 2.7-3 | 3.3-3.6 | 5 |
1.5MM Carbon steel | 1.5-1.8 | 2.5-3 | 4 |
2MM Carbon steel | 1 | 1.8 | 2.5-3 |
3MM Carbon steel |
| 0.8 | 1.5-1.8 |
10MM Acrylic | 0.3-0.36 | 0.9 | 1.2 |
20MM Acrylic | 0.09-0.12 | 0.24 | 0.32 |
5MM MDF(Medium Density Fiberboard) | 1.5-1.8 | 2-2.3 | 3 |
10MM MDF(Medium Density Fiberboard) | 0.6-0.72 | 1.5 | 2 |
Seven advantages of products For Automatic CO2 3d Metal Laser Cutting Machine
1,Cut through steel, stainless steel, carbon steel, alloy steel and other metal;acrylic, wood, plastic, leather and other non-metal
2,With air volume can be as low as 0.2MP
3,Can be continuous drilling, painting line, cutting
4,Can cut 1.5MM thick stainless steel plate
5,Laser head automatic anti-collision function
6,American import servo control system
7,Full servo screw drive structure
Equipment characteristics For Automatic CO2 3d Metal Laser Cutting Machine
1,Using imported linear square rail, the whole screw transmission structure, higher accuracy
2,Full servo motion system, processing precision, stable operation, low noise
3,High power CO2 laser tube, a high efficiency, light spot fine, long time out of light stability is not attenuated
4,The screen control system, data transmission diversity, simple operation, easy to use, powerful, offline, or on-line.
5,Thermostatic cooling industrial refrigeration systems to ensure the life of the laser, and low maintenance.
6,Unique servo system design, consistent beam focus, to ensure that the cutting surface of the gap is small, smooth high.
1. The whole machine has full 1 year warranty, we will send the parts for replacing free of charge during warranty.
2. We will provide lifetime service online, you can get technical support within 24 hours by Email/ Skype/ Remote assistance etx.
3. Profession person reply your questions.
1.What's the guarantee, in case the machine breaks down?
The machine has one years guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client’s feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.
2.How long is the delivery time?
For standard machines, it would be 5-7 days; for non-standard machines and customized machines according to client’s specific requirements, it would be 7 to 10 days.
3.How's the payment?
Telegraphic Transfer(T/T).
4.Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
