Industrial Process PID Digital Mold Temperature Controller

Name: Industrial Process PID Digital Mold Temperature Controller
Brand: Yudian
SKU: 132851869
Availability: InStock

US$ 50 - 100 MOQ: 1 Acre

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Yudian

Model Number:

AI-508

Xiamen Yudian Automation Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Yudian

Model Number AI-508

Usage Industrial

Theory Temperature Controller

AI-508 Artificial Industrial Process PID digital mold temperature controller

Ideal for measurement and controls of temperature, pressure, flow, level, humidity etc.

Main features:

High performance at a low price

High measurement accuracy: 0.3%FS ± 0.1°C

PID, auto tuning, ON/OFF

Universal programmable input

Universal input power- 85-264VAC, or 11-26VAC/VDC

Highly versatile Output, multiple modules available

Wide variety of alarm mode selectable

CE, RoHS, ISO9001 approved

Specification:

Control mode	On-off control mode AI PID Control with Auto Tuning(AT)
Measurement accuracy	0.3%FS ± 0.1°C
Resolution	1°C
Response time	≤0.3s ( when digital filter parameter dL=0)
Input	Thermocouple: K, S, R, T, E, J, N
Input	Resistance temperature detector: Pt100
Input range	Thermocouple: K(-100~1300°C), S(0~1700°C), R(0~1700°C), T(-200~+390°C), E(0~1000°C), J(0~1200°C),B(600~1800°C), N(0~1300°C)
Input range	Resistance temperature detector: Pt100(-200~+800°C)
Output (modularized)	Relay output (NO+NC): 250VAC/2A or 30VDC/1A
	TRIAC Switch Output
	TRIAC zero Crossing trigger output
	SSR Voltage output: 12VDC/30mA (used to drive SSR)
General specifications	Voltage: support AC85-265V,50/60Hz or DC24V.
	Power consumption: ≤3W
	Electromagnetic compatibility (EMC) : ±4KV/5KHz according to IEC61000-4-4; 4KV according to IEC61000-4-5.
	Operating Ambient : temperature -10~60°C; humidity ≤90%RH
