40A/240VAC Solid State Relay SSR
- 9999 Piece / Pieces per Month
- xiamen port
- Credit Card
You May Like
-
40A/415VAC Solid state relay SSR
-
YUDIAN AI-501 single channel digital room temperature alarm meter
-
YUDIAN AI-501 instrument to measure temperature
-
YUDIAN AI-501 single channel digital gas pressure indicators
-
YUDIAN AI-501 single channel digital room temperature alarm meter
-
YUDIAN AI-501 single channel digital room temperature meter
Product Details
| Place of Origin | Fujian, China | Brand Name | YUDIAN | |
| Model Number | SSR40 | Theory | Solid State Relay | |
| Usage | Auto | Size | Miniature | |
| Protect Feature | Other | Contact Load | High Power |
carton box
Product Description
40A/240VAC Solid State Relay SSR
Yudian Solid State Relay SSR15 / SSR20 / SSR25 / SSR40 / SSR40H
___________________________________________________________________________
I. Main Features:
- Economical
- Low disturbance
- Low on-state resistance
- Low output leakage current
- Low current consumption
- Low conducted
___________________________________________________________________________
II. Technical Specification:
| Model | SSR15 | SSR20 | SSR25 | SSR40 | SSR40H |
| Output | |||||
| Load Current | 15A | 20A | 25A | 40A | |
| Load Voltage | 24~240VAC | 24~415VAC | |||
| Dimensions | (58L X 42W X 26H)mm, LED Status Indicator | ||||
| Input | |||||
| Input Voltage | 3V~32V | ||||
| Input Current | ≤8mA | ||||
| Release Voltage | ≤1.2V | ||||
| Max.on-state Voltage Drop | ≤1.2V | ||||
| Max.Leakage Current | ≤2mA | ||||
| Max. Turn-On time (@50Hz) | <10mS | ||||
| Max. Turn-Off time(@50Hz) | <10mS | ||||
| Min. Off-State dv/dt | 500V/μs | ||||
| I/O Insulation Resistance | ≥100M ohm | ||||
| I/O Dielectric Strength | ≥2500V | ||||
| Ambient Temperature | -20℃~80℃ | ||||
___________________________________________________________________________
III. Installation and wiring:
___________________________________________________________________________
IV. Applications
- Industrial Ovens
- Plastics Industry
- Hot Stamping Machines
- Packing Equipment
___________________________________________________________________________
1. How long will you give me the reply?
we will contact you in 2 hours as soon as possible
2. Could I get samples of 40A/240VAC Solid State Relay SSR?
Yes,we have products in stock ,so you can get the samples quickly.
3. How about the quality of the SSR?
We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.
4. Could I visit your factory?
Of course,if you need we will help you to visit our factory.
5. If I have paid,when will you help me to produce?
We will start producing immediately after receiving the payment.
