Help CenterPT100 Temperature Sensor
Related Products
PT100 Temperature sensor
temperature sensor PT100
Code |
Mark |
Use temperature |
Protection tube materials |
Class of accuracy and allowable error |
|
WZP |
PT100 |
-200~500°C |
304 321 316L |
Grade A: +/- (0.15+0.002%|t|) |
|
Grade B: +/- (0.3+0.005%|t|) |
|
Pt thermal |
Graduation mark | ±(°C)Et value on various temperature spots | R100/R0 | ||||||||||
| -200 | -100 | 0 | 100 | 200 | 300 | 400 | 500 | 600 | 650 | ||||
| Pt RTD | Grada | Pt10 0 | 0.55 | 0.35 | 0.15 | 0.35 | 0.55 | 0.75 | 0.95 | 1.15 | 1.35 | 1.45 | 1.3850±0.0005 |
| A | Pt10 | ||||||||||||
| Grada | Pt100 | 1.3 | 0.8 | 0.3 | 0.8 | 1.3 | 1.8 | 2.3 | 2.8 | 3.3 | 3.6 | 1.3850±0.0012 | |
| B | Pt10 | ||||||||||||
| Cu RTD | Cu50 | 1.5 | 0.9 | 0.3 | 0.9 | 1.5 | 2.1 | ———— | ———— | —— | ———— | 1.428±0.002 | |
| Cu100 | |||||||||||||
| Sensor Type | RTD Pt100 element |
| PPCK: RTD Pt1000 element | |
| Probe Diameter (D1) | 3.0mm, 4.0mm, 4.5mm, 6.0mm |
| Detector Elements | Simplex (1 channel) |
| Duplex (2 channels) | |
| Probe Length (mm) (L1) | As required to suit your application |
| Wiring Configuration | 2-wire |
| 3-wire | |
| 4-wire (Simplex only) | |
| Grade of Element | B (Accuracy: ±0.30°C at 0°C, ±0.80°C at 100°C) |
| A (Accuracy: ±0.15°C at 0°C, ±0.35°C at 100°C) | |
| Cable Length (mm) (L3) | As required to suit your application |
| Extension Cable | PVC Insulated (+105°C), 2, 3, 4-wire |
| PFA Insulated (+250°C), 2, 3, 4, 6-wire | |
| Fibreglass/SSB (+400°C), 2, 3, 4-wire | |
| Optional RTD Connector | Miniature RTD Plug |
| Miniature 3-Pin RTD Plug | |
| Standard RTD Plug | |
| Standard 3-Pin RTD Plug | |
| Optional 316 Stainless Steel Compression Fittings | To suit probe Ø: 3.0mm, 4.0mm, 4.5mm, 6.0mm |
Order code
1.model number
2.tube diameter
3.tube length
4.wire material
5.wire length
6.temperature
1)Factory with 25 years experience.
2)Quick delivery ( within 3~5 working days).
3)Retail/Wholesale/OEM/ODM available .
We expect to cooperate with machinery manufacturers, better price for bulk order.
4)We provide after sales service and technical assistance as per the customers requirement and needs.
1. How long will you give me the reply?
we will contact you in 2 hours as soon as possible
2. Could I get samples?
Yes,we have products in stock ,so you can get the samples quickly.
3. How about the quality of the sensor?
We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.
4. Could I visit your factory?
Of course,if you need we will help you to visit our factory.
5. If I have paid,when will you help me to produce?
We will start producing immediately after receiving the payment.
