Specifications
Specifications of stalk press machine:1:low noise durable
2:flexible disassembling
3:safe and reliable
4:CE,ISO,SGS
Brief Introduction of Widely used stalk press machine
Flat die wood pellet mill is specially designed for mass industrial production of wood pellets. The raw materials are easy to obtain, like groundnut shell, sawdust, paddy straw, wheat straw, palm husk, rice husks, etc and many other agro and forestry wastes. The final pellets can be used for industrial boilers and large power plants as well as home heating.
Reamarkable Features of Widely used stalk press machine
1.Main drive adopts high accurate gear drive, with an output of about 20% higher than belt drive.
2. The drive part of the machine including motor optimize, the high quality bearings and oil seals ensure high efficient and steady driving with low noise.
3. The imperative feeder device is adopted, which making the machine operate smoothly as the material like wood sawdust, corn, wheat, and rice straw is very light, so they are needed to be pushed into pelletizing chamber by force.
4. Special design of feed conditioner adopts the frequency-conversion speed regulating control to guarantee wood pellets quality.
5. The flat die is made by international advanced technology, has long service life and ensure smoothly pelletizing and high quality.
6. The international advanced compensation type flexible coupling is of novel and compact structure, safety, low noise and less trouble.
Technical Parameter of Widely used stalk press machine
|
MODEL NO. |
OUTPUT (KG/H) |
POWER (KW) |
PARTICLE SPECIFICA TION (MM) |
DYNAMIC CONFIGUR ATION |
SIZE (MM) |
WEIGHT(PACKAG ED) (KG) |
200 |
100 |
7.5 |
6-8 |
GEAR BOX |
1150*530*750 |
250 |
250 |
150 |
15 |
6-8 |
GEAR BOX |
1250*535*900 |
300 |
300 |
200 |
22 |
6-12 |
GEAR BOX |
1300*600*900 |
600 |
350 |
400 |
30 |
6-30 |
GEAR BOX |
1300*4700*1100 |
600 |
450 |
600 |
45 |
6-30 |
GEAR BOX |
1900*1000*1900 |
800 |
550 |
1000 |
55 |
6-30 |
GEAR BOX |
1700*1600*850 |
1000 |
800 |
1500-2000 |
110 |
6-30 |
GEAR BOX |
1900*1000*1900 |
4500 |
1000 |
2000-2500 |
160 |
6-30 |
GEAR BOX |
2200*1200*2000 |
5500 |
1200 |
2500-3000 |
200 |
6-30 |
GEAR BOX |
2400*1400*2200 |
7000 |
Widely used stalk press machine Photos
Finishied products
Why do you choose us ?
Most Professional |
|
We are a factory specialized in the research and development of feed machinery,there are 23 years experience. |
Sweetest Service |
|
24 hours technical support by email,we will reply within 24 hours.If you need, our engineers can servive for the machine abroad. |
Best Quality |
Our machines have been exported to South America,Africa,Europe, the Middle East etc . |
Guarantee and after-sale Service |
One year guarantee for whole machine except easily damaged parts. |
