Help CenterSZ-08 Mini Wheel Loader
Related Products
Specifications
SZ-08 Mini Wheel Loader1,Changchai engine
2,Low fuel consumption
3,Full hydraulic steering system
4,Low noise
Quick Details
Condition: New |
Brand Name: shenwa |
Model Number: SZ---08 |
Place of Origin: Shandong China (Mainland) |
Type: Front Loader |
Moving Type: Wheel Loader |
Dimension(Long * Breadth * High): 4300*1430*225... |
Rated Load: 800kg |
color: yellow |
Packaging & Delivery
Packaging Detail: |
About 4sets/container Naked |
Delivery Detail |
30 working days shipping after order is confirmed |
Specifications
Loader characteristics:
1,Changchai engine
2,Low fuel consumption
3,Full hydraulic steering system
4,Low noise
- Max.dumping height 2400mm
- Max.dumping distance 900mm
- Max.lifting height 3000mm
- Min.ground clearance 200mm
- Distance between axles 1550mm
- Tread 1200mm
- Overall dimensions(L*W*H) 4300*1430*2250mm
- Engine model Z124YAM
- Rated power 17.6KW
- Rated revolution 2200r/min
- Working pressure 16Mpa
- Max.flux 32ml/r
- Total Weight 2000kg
- Rated loading mass 800kg
- Gradeability 25%
- Min.walking speed 10km/h
- Max.breakout force 20kn
- Min.rotary radius 3200mm
Performance characteristics
1,Single-cylinder 24hp motor,with smooth discharge,low noise,less oil consumption,the power transmission system is driving and reliable.
2,Novel appearance and model,capacious operator cabin,favorable eyeshot.
3,Hydraulic system with steering preferential,with high efficiency and can save energy,the dynamaic performance of which is better.
4,Convenient back cover for repairing,centralized lubricating system,which is comvenient to maintain and upkeep.
5,Fork-type carriage,the stability of the complete appkiance is good,and the structural strength is high.
6,Ascendant performance of complete appliance,with extraordinary operation efficiency.
7,With which many kinds of optional compinents can be matched to meet requirements of different users.
Update Date:2010-10-19 03:30:24
