Help CenterFour Wheel Drived Loader
Related Products
four wheel drived loader
Quick Details
Condition: New |
Brand Name: shenwa |
Model Number: SZ-10 |
Place of Origin: Shandong China (Mainland) |
Type: Mini Loader |
Moving Type: Wheel Loader |
Dimension(Long * Breadth * High): 4600*1620*240... |
Rated Load: 1000KG |
engine model: QC2105 |
color: required |
Packaging & Delivery
Packaging Detail: |
nuded package |
Delivery Detail |
30 days after the order is confirmed |
Specifications
1 With humanized equipments
2 Low fuel consumption
3.Low noise
4 Hydraulic dual-variable
5.Full hydraulic steering sys
Max.dumping height 2400mm
Max.dumping distance 900mm
Max.lifting height 3200mm
Min.ground clearance 200mm
Distance between axles 2130mm
Tread 1400mm
Overall dimensions(L*W*H) 4600*1620*2400mm
Performance characteristics:
Rated power 24KW
Rated revolution 2200r/min
Working pressure 16Mpa
Max.flux 32ml/r
Total Weight 2700kg
Rated loading mass 1000kg
Min.rotary radius 3500mm
1.Double-cylinder 33hp motor,with smooth discharge,low noise,less oil consumption,the power transmission system is driving and reliable.
3.Rear cylinder hood type can easy maintenance.5.Ascendant performance of complete appliance,with extraordinary operation efficiency.
4.Fork-type carriage,the stability of the complete appkiance is good,and the structural strength is high.
6.With which many kinds of optional compinents can be matched to meet requirements of different users.
Update Date:2010-10-19 01:48:24
