SZ-09 four-wheel drive loader
WORKING RANGE
MAX.DUMPING HEIGHT 2400mm
MAX.DUMPING DISTANCE 900mm
MAX.LIFTING HEIGHT 3200mm
MIN.GROUND CLEARANCE 200mm
DISTANCE BETWEEN AXLES 2245mm
TREAD 1400mm
OVERALL DIMENSION(L*W*H) 4600*1620*2330mm
ENGING
MODEL Z128YAM
RATED POWER 20.23KW
RATED REVOLUTION 2200r/min
HYDRAULIC SYSTEM WORKING PRESSURE 16Mpa
MAX.FLUX 32ml/r
SPECIFICATIONS
RATED LOADING MASS 800Kg
GRADEABILITY 25%
MIN.WALKING SPEED 10km/h
LIFTING TIME OF MOVABLE ARM 4.5s
SUMMATIONAL TIME 10s
LIFTING TIME OF MOVABLE ARM 3.0s
MAX.WALKING SPEED 25km/h
MAX.GROUND CLEARANCE 20kn
MIN.GROUND CLEARANCE 3500mm
