25Mpa , 8038.8Nm3 , ISO 11120, 11-Tube Bundle CNG Container. Truck Trailer

Name: 25Mpa , 8038.8Nm3 , ISO 11120, 11-Tube Bundle CNG Container. Truck Trailer
Brand: LUXI
SKU: 132794997
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

LUXI

Model Number:

GSJ11-2320-CNG-25

Luxi New Energy Equipment Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China (mainland)

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name LUXI

Model Number GSJ11-2320-CNG-25

Type CNG

Application:

1. For CNG transportation from Mother station/ gas reserve to daughter station;

2. For CNG transportation to places where pipeline network hasn’t been built;

3. For CNG transportation to places where can’t reach existing distribution system etc;

4. For CNG storage at gas stations.

11-tube bundle container
Execution standard : ISO11120 Cylinder-design , structure and test of seamless and reusable steel tube with a capacity between 150 L to3000 L . ISO 668 Classification , dimensions and ratings of series 1 container
Tube Bundle Container	Item	data	Cylinder	Item	data
	Type	GSJ11-2320-CNG-25		Working pressure	25MPa
	Net weight	29650Kg		Working temperature	-50~65°C
	Filling weight	5788Kg		Main material	30CrMoLX
	Total weight	35438Kg		cylinder QTY	11
	Hazard class	2.1		Total volume	25.52M3
	UN code	1049		Hydrostatic test pressure	37.5MPa
	Medium	CNG		Dimension	559x14.8x10977
	Leakage test pressure	25MPa		Design temperature	65°C
	Hydrostatic test pressure	37.5MPa		Medium property	Explosive
	Loading volume	8038.8Nm3	Bursting discs	Burst pressure	37.5MPa
	Dimension	12192x2438x1890		Burst pressure	37.5MPa
	Transporting	Highway combined transport		Bursting disc device discharge aperture	≥20
	Design service life	15		Bursting disc device discharge aperture	≥20
