Hot Sales 365nm 130W High Power uv Led Module for Coating Line

Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-1
Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-2
Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-3
Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-4
Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-5
Hot Sales 365nm 130W High Power uv Led Module for Coating Line thumbnail-6
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-1
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-2
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-3
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-4
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-5
Hot Sales 365nm 130W High Power uv Led Module for Coating Line photo-6
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
T004A4V08S11P4
Chip Material:
InGaN
Emitting Color:
Other, Purple
Contact Supplier Request Quote Chat Now
Shenzhen HCEN Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Guangdong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number T004A4V08S11P4
Chip Material InGaN
Emitting Color Other, Purple
Luminous Intensity 14300
Luminous Flux(lm) 14300
Optical Attenuation(%) 7
Power Other, 135W
Power Dissipation 132
Color Rendering Index(Ra) 90
Color Temperature Ultraviolet
Operating Temperature(℃) -40, +100
Storage Temperature(℃) -40, +85
Place of Origin Guangdong, China
Brand Name HCEN
Certification CE
Product Description

Features:

1.Size:56mm*27.5mm*1.5mm
2.Long operating life
3.High reliability
4.RoHS compliant


Applications:

1.Ink curing
2.Resin curing
3.Fluorescence excitation
4.Lithography


Characteristics of UV LED modules

(1) Absolute Maximum Rating at TA=25°C

Parameter
Symbol
Rating
Units
Input Power
Pi
132
W
DC Forward Current
IF
2800
mA
Junction Temperature
Tj
125
°C
Operating Temperature Range
Topr
                                 -40°C TO +85°C
Storage Temperature Range
Tstg
                                 -40°C TO +100°C

(2) Electrical/Optical Characteristics

Parameter
Symbol
Typ
Units
Peak Wavalength
λp
365
nm
Radiant quantity
ω
14300
mJ/cm2
Radiant quantity
ω
3300
mJ/cm2
Radiant quantity
ω
1200
mJ/cm2
Forward Voltage
VF
38-42
V
Spectrum Half Width
Δλ
14
nm

Notes:

1.Peak wavelength measurement tolerance:±3nm

2.Radiant quantity measurement tolerance:±10%

3.500mA is single light emitting diode DC forward current

4.Distance between light exiting surface and UV energy apprantus

5. ω is the total radiant quantity as measured with an UV energy appratus

Splicing of the Module

▲This module is adapted to the transverse splicing which forms a line source

▲Connection way of this module is flexible,which can be composed of linear light source or a surface light source

▲ UV LED Linear Light  Source                                                            ▲UV LED Surface Light Source

UV Curing Process:
Product Applications

Main Applications of This UV LED Module:It is used for uv curing systems, uv gel  lamp,lithography,coating curing.,ect.

Our Advantages

UV LEDS offer many advantages toward UV lamps:

Certifications
Packing & Delivery

Packing Informations:IN anti-static package then in Carton

1.Payment term: T/T, L/C ,Western Union,Paypal .,ect.
2.Delivery:Carrier is available by express,or sea shippiung or ordinary air cargo.

Our Company

Shenzhen HCEN Technology CO.,LTD located in the east bank of the Pearl River Delta and near Hong Kong.HCEN brand is registered in October 17, 2014, with registered capital is RMB200 million RMB.

Headquartered in Shenzhen, HCEN also have branch in Shanghai, Beijing and Hong Kong. We have marketing and technical supporting teams in Munich Germany, Bangkok Thailand and Malaysia .

As a promoter of UV LED technology, HCEN own professional UV LED R&D team ,soulution engineers to give full support of our customer. HCEN invest about 10%-20% of the sales volume to develop new products.

Our Service

UV LED Solution Team

HCEN is a professional UV LED solution provider,supported by 22 application engineers and R&D experts backing from Japan and Germany.They are experienced in UV LED encapsulation,optical design and led cooling solution. Tell us your application and then we provide you the tailored solutions

Sample Policy:

We support free samples for testing! You just need to pay the shipping cost.


Guarantees/Warranties/Terms and Conditions:

We guarantee our products to be free from manufacturer defects.Warranty and free maintance time about 12 month-24 month.

FAQ

Q1:Are you a Factory or Trading Company?

Answer: Factory.

Q2:How can I visit your factory?

Answer:Since you come to Shenzhen,contact us before you come,we will pick you up directly to our company.

Q3:When can I get the price?

Answer:Within 24 hours we get your inquiry and confirm the needs and solution.

Q4:How can I get a sample to check your quality?

Answer: After price and payment confirmation, we are honored to send you.

Q5:Can you provide a solution for UV LED substitute for UV Lamp ?

Answer: Pls provide UV Lamp data heet,wavelength,required optial power or radiant intensity . radiant distance and curing area,more info. will help us to provide a exact solution for your application.

Q6:What’s the universal Lead-Time for order delivery?

Answer:1)7-15 Working days for led diodes undering quantity of 10k.

2)10-30 Working days for curing system and UV LED module

3)Samples will be delivered as soon as payment confirmed .

Q7:What’s the payment terms?

Answer:We can accept T/T,and Paypal.
