Best Tfo twisting machine for Chemical fiber From China Factory
- 500 Set / Sets per Month
- Ning Bo OR Shang Hai
Product Details
| Condition: | New | Type: | Other, Chemical Fiber | Place of Origin: | Zhejiang, China |
| Brand Name: | XIANQU | Model Number: | XQ328G | Voltage: | 380V |
| Power(W): | 19kw | Dimension(L*W*H): | 24500*840*1900mm | Certification: | ISO9001:2008 |
| Warranty: | One Year | After-sales Service Provided: | Overseas third-party support available |
Product Description
Features:
1.The thermal box is of German technology to achieve stable temperature a still longer and more stable service life.
2.A Japanese technology is applied to achieve a more stable spindle speed.
3. The integrated mechanico-electrical design to make operation and management much easier.
Technical Specification
| Number of Spindles | 192 Spindles As Basic Number(16 Multiplication and so on) | Type | Two Side,Single Layer |
| Spindle Distance | 225mm | Spindle | Spindle Bell Wheel Diameter:Φ28 |
| Spindle Speed | 9000-16000 rpm | Faise Twist Range | Motors for winding and spindles are separate. Theoretically the number of thrns are settable as one likes and intinitely regulatable |
| Twis Direction | S or Z | Tension Control | Multi-sectional tension ball and tensiong ring are jointly put in use. |
| Maximum Winding Capacity | Φ160*152 | Applicability | 50D-400D Polyester & Chemical Fiber Filament Yarns |
| Unwinding Spool Specification | Φ110*Φ42*270-290 | Max.Speed of the false twister rotor | 260000RPM |
| Electro-Thermal Power | 10.5kw | Thermal Box Yarn-Pass Length | 400mm |
Overall size | 24500*840*1900mm | Winding Angle | Regulatable at will |
Xinchang Pioneer Machinery Science & Technology Co., Ltd. Is located in Xinchang County, Zhejiang Province, founded in 1993, a manufacturing enterprise specializing in making the two-for-one twisting machines, doubling winder machines, yarn covering machines and etc.
The Company possesses advanced processing equipment, perfect test means and strong technical force, has established the perfect EPR control system and checks every management item by means of ISO9001-2008.
Basic Information
Business Type: | Manufacturer, Trading Company | |
Main Products: | Yarn Covering Machine,Bobbin Winder,Winding Machine,Twisting Machine,Textile Spindle | |
Number Of Employees: | 51 - 100 People |
Trade & Market
Main Markets: | Domestic Market, Southeast Asia, Mid East, Eastern Europe,etc | |
Total Annual Sales Volume: | US$2.5 Million - US$5 Million | |
Export Percentage: | 21% - 30% |
Factory Information
Factory Size (ters): | 3,000-5,000 square meters | |
Factory Location: | No. 5 Ling Chi Road, Xinchang County., Zhejiang, China. | |
No. of Production Lines: | 4 | |
Number of R&D Staff: | 5 - 10 People | |
Number of QC Staff: | 5 - 10 People | |
Contract Manufacturing: | OEM Service Offered Design Service Offered Buyer Label Offered |
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing,debugging, operation of the machine, it will indicate you how to use this machine well.
2.Clients Traning Services
We can train your staff to use your equipment systems properly.It means that we offer Customers Training, teaching
how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.
3.After Sales Service
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of
supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance
options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
In one words,your satisfication is our persuit forever!
1.What is your advantage compared with other textile manufacturers?
We are expert at making yarn machines for almost 20 years and we have a professional technical team who can provide special customer requirements, so that we are able to make machines with high quality and reasonable price.
2.What kind of service can you offer?
Design with your requirements by professional team. ISO 9001:2008 certificates and letters patent. Engineers go overseas for training.
3.How to check my order at last?
We warmly welcome you to visit our company in XinChang, which is close to NingBo, for checking your machines. If you don’t come here, we can also take photos and videos for your conformation.
4. How many years Guarantee?
12 month after the B/L date
5.Does the machine with inveter or not?
Yes With inverter
6.If you supply the installation service :
Yes By your requirement we can send our technical to install the machine for you ,But you need to bear all the cost
