Help CenterFBTYPE CARDING MACHINE WITH CHUTE FEEDER
Related Products
-
High-perfpormance Semi-worsted Carding Machine for Cotton FB TypeUS$ 1 - 2MOQ: 1 Set -
FB200 CARDING MACHINE FOR CASHMEREUS$ 1 - 2MOQ: 1 Set
-
Fiber Carding Machine for Cotton and WoolUS$ 1 - 2MOQ: 1 Set
-
SEMI-WORSTED CARDUS$ 1 - 2MOQ: 1 Set
-
Qingfeng Cashmere Carding Combination MachineUS$ 1 - 2MOQ: 1 Set
Specifications
Short flow, smart technology. Particular application to customers with various kinds of materials and small quantity.Appication
It is mainly used for blending medium and short fibers ranging from nature fibers like cotton, cashmere, woolen, silk and flax to artificial fibers and chemical fibers.
simple structure :feeding bucket FB009+
Semi-worsted Carding Machine FB201A
1.Feeding Bucket FB009
Application
Aligned with one feeder, this bucket can function as a semi-worsted production line with a high application in blended materials with single or multiple ingredients. After blended, pre-opened and impurities removed, materials will be turned into even slivers and then fed onto carding machines.
Main Feature
Under the interaction of rollers and spiked lattice, raw materials received on this bucket will be further opened and impurities will be removed
Frequency control of spiked lattice to meet different productivity.
Volumetric vibrating feeder to ensure uniform output
Photocell switch control to avoid discontinuous feeding
Main Parameter and Specification:
Working Width 960mm
Installed Power 1.5KW
Dimension: (L*W*H): 2160 ×1222×2700 (mm3)
Productivity:6~22kg/h
2.Semi-worsted Carding Machine FB201A
Application
This machine is used to process cotton and chemical fiber. Twisted cotton or chemical fiber from the front process are basically straightened to single fiber,during that process seeds,impurities and short fiber left from the cleaning process are removed, then the cotton becomes certain count sliver and stored in the coiler for next step.
Main technical parameters and specifications
Productivity 15~30kg/h
Working width 1000mm
Installed power 4.11kw
Space occupation 3684×2009mm
Net weight 4.5T
