Automatic vacum cheese salt packing machine
- 60 Set / Sets per Month
- Guangzhou Foshan Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
-
Maquillageplastic sealing heat shrink packaging machine Seal and shrink the film packaging machine
-
Express deliverybox packing and paste sheet packing machine Box sealing and paste single package all-in-one machine
-
Maquillagemembrane packing machine
-
Bookseal the heat-shrink packaging machine Seal and shrink the film packaging machine
-
Automatic Screw Counting Packing Machine
-
Maquillagemembrane packing machine Gift packageseal and cut the packaging machine
Product Details
| Condition: | New | Function: | Filling, Labeling, Sealing | Application: | Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical |
| Packaging Type: | Bags, Film, Pouch, Stand-up Pouch | Packaging Material: | Plastic | Automatic Grade: | Automatic |
| Driven Type: | Pneumatic | Voltage: | 220V,50/60HZ | Power: | 2.2KW |
| Place of Origin: | Guangdong, China | Brand Name: | BAOPACK | Model Number: | CB-VD32(Spray painting) |
| Dimension(L*W*H): | (L)2150*(W)1710*(H)2040mm | Certification: | CE/ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic vacum cheese salt packing machine
SPECIFICATIONS:
| Item | Content |
| Model | CB-VD32(Spray painting) |
| Max film width | 320mm |
| Accuracy | ≤1.5% |
| Die way | Double pull |
| Max packing speed | 80 bag/min |
| Film thickness | 0.04--0.09mm |
| Type of bag making | Pillow bag, gusseted bag, punching bag,vacuum bag |
| Bag size | (L)50-200(w)60-150mm |
| Voltage | 2.2kw, 220v, 50/60HZ |
| Air consumption | 0.8Mps 0.25m³/min |
| Net weight | 300KG |
| Dimension | (L)1115X(W)800X(H)1370mm |
| Package material | BOPP/CPP/VMCPP,BOPP/PE,PET/VMPET, PE,PET/PE,etc |
Please watch video about principle of operation as following
link https://youtu.be/NsYhPxEsFQs
Main Features:
1: Famous brand PLC control system, wide version touch screen, convenient to operate.
2: Film drawing down system and horizontal sealing controlled by servo motor.
3: Perfect alarm system to reduce waste.
4: It can complete feeding, measuring, filling, sealing, date printing, charging(exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.
Pre-sales Services:
BAOPACK have the best salesmen to provide the most professional services.
Standing in the perspective of the customer to solve your queries.
Medium-sales Services:
BAOPACK have the trained team to follow your orders methodically to guarantee
the products can be finished on time with high quality.
After-sales Services:
BAOPACK have the technician team with many years of technical experience to
provide you the most professional after-sales services.
Q1: Can you send me the video of this machine in operating mode?
A: Yes, please check the link for this video https://youtu.be/NsYhPxEsFQs
Q2:What is the material of contact food/material parts?
A: The contact food/material parts are made of 304# stainless steel.
The machine body can be 304# stainless steel or carbon steel.
Q3:Can this machine make different bag sizes?
A: One former can make one bag width, and the bag length can be adjustable within a range.
It should be ordered an extra former if you want to make the other bag width.
Q4: Does your company accept OEM?
A: Yes, we have a professional design and technical team to accept customization.
Q5:When you can deliver the machine after the order is placed?
A: We usually can arrange shipment after 30-40 working days,
but it depends on the quantity of the products.
Q6:How about your warranty?
A: We provide one year warranty and lifelong maintenance.
Q7:What can you provide after service?
A: We can provide machine testing video and pictures before delivery,
English manual, some free spare parts, installation in clients' factory and technical training.
Automatic vacum cheese salt packing machine
