The SHJS series two-stage extruder consisted of two stage components. The first stage is SHJ co-rotating twin-screw extruder, the second stage is SJ single screw extruder. This machine first of all to realize material better compounding and shearing by twin-screw, then the single screw fulfills the task of extruding and granulating.
The scientific and advanced structure can avoid material decomposition phenomena due to overheating. To combines the advantage of twin-screw and single screw together and complementation, likewise, propitious to every craft distribution and optimize so that making higher efficient and production capacity.
The two-stage extruder best suits for producing PVC, POM, XLPE thermo-sensitive material etc.
1.Techincal Data:
Model |
D(mm) |
L/D |
n(r/min) |
P(kw) |
Q(kg/h) |
|
SHJS50-100 |
SHJ-50 |
50.5 |
24-48 |
500 |
37/45 |
100/300 |
SJ-100 |
100 |
7-20 |
85 |
30/37 |
||
SHJS65-150 |
SHJ-65 |
62.4 |
24-48 |
500 |
55/75 |
200/500 |
SJ-150 |
150 |
7-20 |
85 |
37/45 |
||
SHJS75-180 |
SHJ-70 |
71.0 |
24-48 |
500 |
90/110 |
400/800 |
SJ-180 |
180 |
7-20 |
85 |
45/55 |
||
SHJS95-200 |
SHJ-95 |
93.0 |
24-48 |
400 |
200/250 |
700/1500 |
SJ-200 |
200 |
7-20 |
85 |
55/75 |
||
2. Certificate:
3. Manufacturer
4. Exhibition
