Y-150B Stainless steel pressure gauge
Brief Description
Y-150B Stainless steel pressure gauge is used to measure pressure of various liquid medium in oil, chemical industry, chemical fiber, metallurgy, and power plants widely, it’s corrosion-proof and vibration-proof.
Structure Principle
This gauge consists of pressure pilot system (including joint, spring tube, current limiting screw), gear transmission system, indicating device (needle and scale plate) and shell (including shell, cap, glass). Shell is airtight which protect the gauge from environmental influence and dirt.
For gauges of which the external shell is filled with liquid (always be silicon oil or glycerol oil), which can resist strong vibration and reduce pulsation effect of medium pressure.
Technical Parameters
Environmental temperature: -25~70℃ (external shell is filled with liquid)
-40~70℃ (external shell is not filled with liquid)
Temperature influence: not more than 0.4%10℃ (working temperature deviation 20±5℃)
Anti-vibration grade: V H 4 (external shell is filled with liquid)
V H 3 (external shell is not filled with liquid)
Casing protection grade: IP64
Weight: 0.2kg (Y-60B-F)
0.6kg (Y-100B-F)
1.0kg (Y-150B-F)
Model and Specifications
Model |
Scale range, MPa (Hg~Psi) |
Accuracy |
|
Y-60B-(F) Y-60B-(FZ) Y-63B-(F) Y-63B-(FZ) |
0~0.6,1,1.6, 2.5,4,6,10, 16, 25, 40,60 -0.1~0.5,0.9,1.5, 2.4 |
2.5 |
|
Y-100B-(F) Y-100B-(FZ) Y-150B-(F) Y-150B-(FZ) Y-103B-(F) Y-103B-(FZ) Y-153B-(F) Y-153B-(FZ) |
0~0.1,0.16,0.25,0.4, 0.6, 1,1.6, 2.5, 4, 6, 10,16,25,40,60 -0.1~0,0.06,0.15,0.3,0.5, 0.9,1.5, 2.4 (-30’-0,15,30,60,100,150; 0~15,30,60, 100, 200, 300,400,600, 800, 1000, 1500, 2000,3000, 4000, 6000, 10000) |
1.5 (1) |
Note: scale range and accuracy in bracket ( ) is for special order
Material of pressure system and casing
|
Components |
Material |
|
Y-60B |
Y-100B,Y-150B |
|
Joint |
0Cr18Ni9(304) |
0Cr17Ni12Mo2(316) |
Spring tube |
0Cr18Ni9Ti(321) |
0Cr17Ni12Mo2(316) |
Casing |
0Cr18Ni9(304)
|
|
