D500/7D pressure controller has diaphragm type sensor, can be used in neutral gas and water, hydraulic oil, lubricating oil, light fuel oil etc. Controller setting value is adjustable, range is 0~2.5MPa.
Technical Parameters
Working viscosity: <1,10-3m2/s
Switch: micro switch
Housing protection: IP65 (DIN40050, same as IP65 in GB4208)
Environment temperature: -5~40℃
Medium temperature: 0~90℃
Vibration-resistant: D500/7D:40m/s2 D500/7DK:20m/s2
Repeatability error: ≤1.5%
Contact capacity: AC 380V 6A(resistance)DC 24 0.25A
Specifications
D500/7D switch difference is not adjustable(setting value is adjustable)
|
Setting value Range MPa (KPa)
|
Switch difference not more than |
Rated Pressure *MPa |
Switch frequency |
Sensor material |
Female thread |
Weight Kg |
Overall size |
Ordering No.
|
||
Setting value Range lower limit MPa |
Setting value Range Upper limit MPa |
Housing |
Diaphragm |
|||||||
|
(-2.5-2.5) (-5-5) (0-16) (0-25) |
(0.2) (0.4) (0.4) (0.4) |
(0.2) (0.6) (0.8) (0.9) |
(50) (50) (50) (50) |
10 |
galvanized steel
|
316 |
G1/4” G1/4” G1/4” G1/4” |
1.0 1.0 1.0 1.0 |
01 01 01 01 |
0812200 0812500 0812700 0812800 |
|
0.005-0.06 0.005-0.1 0.005-0.16 0.005-0.25 |
0.003 0.003 0.003 0.004 |
0.006 0.009 0.012 0.015 |
1.5 1.5 1.5 1.5 |
G1/4” G1/4” G1/4” G1/4” |
1.15 1.15 1.15 1.15 |
01 01 01 |
0814100 0814200 0814300 0814400 |
|||
|
0.03-0.4 0.03-0.6 0.03-1. |
0.02 0.03 0.03 |
0.04 0.05 0.06 |
10 10 16 |
40 |
304 |
G1/4” G1/4” G1/4” |
0.85 0.85 0.85 |
02 02 02 |
0814500 0814600 0814700 |
|
|
0.1-1.6 0.1-2.5 |
0.04 0.04 |
0.12 0.15 |
20 20 |
G1/4” G1/4” |
0.85 0.85 |
03 03 |
0814800 0814900 |
|||
D500/7D switch difference is adjustable(setting value is adjustable)
|
Setting value Range MPa |
Switch difference not more than MPa |
Rated Pressure *MPa |
Switch freq- uency |
Sensor material |
Female thread |
Weight Kg |
Overall size |
Ordering No.
|
||
Setting value Range lower limit |
Setting value Range Upper limit |
Housing |
Diaph- ragm |
|||||||
|
(-2.5-2.5) (0-5) (0-16) (0-25) |
(0.8-2.5) (0.9-4) (1.1-12) (1.1-20) |
(1.1-2.5) (1.5-4) (2.3-12) (2.8-20) |
(50) (50) (50) (50) |
10
|
galvanized steel
|
316 |
G1/4” G1/4” G1/4” G1/4” |
1.05 1.05 1.05 1.05 |
01 01 01 01 |
0802200 0802500 0802700 0802800 |
|
0.005-0.06 0.005-0.1 0.005-0.16 0.005-0.25 |
0.009-0.05 0.011-0.08 0.013-0.12 0.014-0.2 |
0.016-0.05 0.018-0.08 0.025-0.12 0.025-0.2 |
1.5 1.5 1.5 1.5 |
G1/4” G1/4” G1/4” |
1.20 1.20 1.20 1.20 |
01 01 01 |
0804100 0804200 0804300 0804400 |
|||
|
0.03-0.4 0.03-0.6 0.03-1 |
0.05-0.2 0.06-0.4 0.06-0.6 |
0.08-0.2 0.1-0.4 0.11-0.6 |
10 10 16 |
40 |
304 |
G1/4” G1/4” G1/4” |
0.9 0.9 0.9 |
02 02 02 |
0804500 0804600 0804700 |
|
|
0.1-1.6 0.1-2.5 |
0.12-1.2 0.12-2 |
0.25-1.2 0.33-2 |
20 20 |
G1/4” G1/4” |
0.9 0.9 |
03 03 |
0804800 0804900 |
|||
