Glass rotor flow meter is widely used in chemical industry, oil, light industry, medicine, chemical fertilizer, chemical fiber, food, dyeing, paper making, environment protection and scientific research department to measure flow of non-pulse one-direction gas or liquid.
Principle and structure
The main measuring element of glass rotor flow meter is a glass tube with small end down, big end up and a floater which move down in it. When the fluid flows through the cone glass from bottom to top, a differential pressure generated between upper and lower of the floater, and the floater will be rising under the differential pressure. When the resultant force offloat upward force, gravity and buoyancy of floater and viscous force is equal, the floater in a state of balance. Therefore, the fluid flow of the meter and the height of rising fluid have certain relation with the meter’s flow area, and the height of floater can be as flow rate.
Technical parameters
Model |
LZB-15 |
LZB-25 |
LZB-40 |
LZB-50 |
LZB-80 |
LZB-100 |
|
DN(mm) |
Φ15 |
Φ25 |
Φ40 |
Φ50 |
Φ80 |
Φ100 |
|
Measuring ratio |
1:10 |
1:10 |
1:10 |
1:10 |
1:10 1:5(GAS) |
1:05 |
|
Working pressure(MPa) |
≤0.6 |
≤0.6 |
≤0.6 |
≤0.6 |
≤0.4 |
≤0.4 |
|
Accuracy |
2.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
Flow range |
liquid(m3/h) |
16-160(L/h) |
40-400(L/h) |
0.16-1.6 |
0.4-4.0 |
|
|
25-250(L/h) |
60-600(L/h) |
0.25-2.5 |
0.6-6.0 |
1.6-16 |
8-40 |
||
40-400(L/h) |
100-1000(L/h) |
|
|
|
|
||
Gas(NM3/h) |
0.25-2.5 |
|
4-40 |
10-100 |
50-250 |
120-600 |
|
0.4-4.0 |
1.6-16 |
6-66 |
16-160 |
80-400 |
200-1000 |
||
0.6-6.0 |
2.5-25 |
|
|
|
|
||
