High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor

High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-1
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-2
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-3
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-4
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-5
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor thumbnail-6
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-1
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-2
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-3
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-4
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-5
High Quality Radial and Axial Metallized Polyester Cbb21dain Film Capacitor photo-6
US$ 0.03 - 0.54 MOQ: 3000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
DAIN
Model Number:
MEF
Contact Supplier Request Quote Chat Now
Dain Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Taichung Keelung Kaohsiung
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name DAIN
Model Number MEF
Type Polyester Film Capacitor
Application General Purpose
Package Type Other
Capacitance 0.01uF ~ 10 uF
Rated Voltage 100, 250, 400, 630VDC
Operating Temperature -40℃~ +85℃

High quality Radial and axial metallized polyester cbb21dain film capacitor







Product Description

 High quality Radial and axial metallized polyester cbb21dain film capacitor

MEF type is self-healing flat style capacitor which is winging with Metallized Polyester Film as dielectric, epoxy resin dip coated and with radial CP wire.

 Electrical Characteristics

Operating Temperature : -40℃~ +85℃

Capacitance Tolerance : J (±5%), K (±10%), M( ±20%)

Capacitance Range: 0.01uF ~ 10 uF

Dissipation Factor: 1% Max, at 1 KHz and 25℃

Insulation Resistance: ≥15000MΩfor C≤0.33uF



                                        ≥5000MΩ.uF  for C>0.33uF

Rated Voltage: 100, 250, 400, 630VDC

Dielectric Strength: 175% of rated voltage for 3 - 5 sec.

Dimensions: (mm) (Max.)

◊ DAIN’s products are RoHs.

CODE MFD 100VDC 250VDC 400VDC 630VDC
L H T P d L H T P d L H T P d L H T P d
±0.08 ±0.08 ±0.08 ±0.08
103 0.01 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6
153 0.015 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 6 10 0.6
183 0.018 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6
223 0.022 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 11 6.5 10 0.6
333 0.033 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 18 11 6 15 0.8
473 0.047 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 11 6.5 10 0.6 18 12 7 15 0.8
563 0.056 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 10 5.5 10 0.6 18 12 8 15 0.8
683 0.068 12 10 5.5 10 0.6 12 10 5.5 10 0.6 12 11 6.5 10 0.6 18 13 8 15 0.8
104 0.1 12 10 5.5 10 0.6 12 10 5.5 10 0.6 18 11 7 15 0.8 18 15 9.5 15 0.8
154 0.15 12 10.5 7 10 0.6 12 10.5 7 10 0.6 18 13 8 15 0.8 23 16 9 20 0.8
224 0.22 12 11 7.5 10 0.6 18 11 7 15 0.8 18 14 9.5 15 0.8 23 18 11 20 0.8
334 0.33 12 11 8 10 0.6 18 12 7 15 0.8 23 16 8.5 20 0.8 31 17.5 10.5 27 0.8
474 0.47 18 11 6.5 15 0.8 18 13 8 15 0.8 17 12.8 8 15 0.8 31 21.5 12 27 0.8
564 0.56 18 11.5 7.5 15 0.8 18 14 9 15 0.8 23 19 12 20 0.8
105 1 18 15 9 15 0.8 23 17 9.5 20 0.8 31 20 12 27 0.8 31 28 18 27 0.8
155 1.5 23 17 9 20 0.8 23 18 11 20 0.8 31 23 13 27 0.8
225 2.2 23 18 10 20 0.8 31 20 12 27 0.8 31 27 16 27 0.8
335 3.3 23 22 13 20 0.8 31 22 14 27 0.8 31 28 17 27 0.8
475 4.7 31 23 13 27 0.8 31 24.5 15 27 0.8
685 6.8 31 24 16 27 0.8 36 25 16 33 0.8
106 10 31 26 21 27 0.8







Machinery Equipment

◊ Machinery and Equipment

High quality Radial and axial metallized polyester cbb21dain film capacitor



◊Testing Instrument

High quality Radial and axial metallized polyester cbb21dain film capacitor





Buying Guides
Lead time 14-35 days (If no stock) ; but it can be change by your request
Payment
 T/T in advance
Shipping way By SEA, AIR, Express



Related products

High quality Radial and axial metallized polyester cbb21dain film capacitor

Our services

◊ Dain Five Promises

High quality Radial and axial metallized polyester cbb21dain film capacitor



♦Because there are many faked DAIN products in China , we highly recommend you to contact and purchase with original DAIN company (TAIWAN) directly to ensure quality of your product.



A specialized manufacture of capacitor since 1989.

Over 26 years capacitors production experiences.

Reliable capacitor, reliable partner.

Looking for high quality supplier, come to Dain, don't hestiate to contact with us!
