ETA-068F Coating paint Thickness Meter,ultrasonic thickness meter

Specifications

ETA-068F Coating paint Thickness Meter
Measure range: 0-1000um
Measure precision:(3%-1.5)
Display precision: 0-99.9UM:0.1U

Coating Thickness Meter,ultrasonic thickness meter



This instrument adopts the magnetism measuring thickness methods. It can measure the thickness of the covering layer of non-magnetism (such as aluminum, chrome, copper, enamel, rubber and oil paint) which are covered on the magnetism metal substrates (such as steel, iron, alloy and rigid magnetism steel) It has many characteristics, such as little error of measuring, excellent performance, good stability and easy operation. It is such a necessary measure instrument to control and guarantee the product quality that it is widely applied to manufacturing, metal processing industry, chemical industry and merchandise testing field.



Test method: The magnetism
Measure range: 0~1000um
Measure precision: ±(3%H±1.5)
Display precision: 0~99.9um:0.1um/ Over 100um:1um
Statistic function(single measure): Average value, maximum value, minimum value, measure times
Minimum substrate: 10*10 mm
Minimum curvature: Protruding5mm,concave25mm
Most thinnest substrate: 0.5mm
Environment temperature: 0 C~40C

Relative humidity: ≤85%
Power: DC9V×1
