Help CenterPrecision Roughness Instrument & High Precision Roughness Meter NDT150
Related Products
-
Handheld Roughness Meter NDT120NegotiableMOQ: 10 Pieces -
Pocket Surface Roughness Meter NDT110NegotiableMOQ: 10 Pieces
-
ETA-068F Coating Paint Thickness Meter, Portable Thickness MeterNegotiableMOQ: 5 Pieces
-
Laser LV02 Digital Laser LevelNegotiableMOQ: 100 Pieces
-
ETB-0833 Gloss MeterNegotiableMOQ: 50 Pieces
Handheld roughness meter NDT120
| Measurement parameters Ra, Rz = Ry (JIS), Rq, Rt = Rmax, Rp, Rv, R3z, R3y, RzJIS, Rs, Rsk, Rku, Rsm, Rmr | |
| Measuring range Ra: 0.005 um ~ 16.00 um | |
|
Display range Ra, Rq: 0.005 um ~ 16 um; Rz, Rv, R3z, Rt, Rp, R3z ,: 0.02 um ~ 160 um Rsm, Rs: 1mm; Rmr: 0 ~ 100%; Rsk: 0 ~ 100% |
|
| ndication accuracy 0.001um | |
| Indication error ≤ ± 7% | |
| Changes indication of <6% | |
| Internal storage capacity of 100 sets of data | |
| Data Interface USB | |
| Dimensions 141 mm × 55 mm × 40mm | |
| Working conditions temperature: -20 ℃ ~ 60 ℃ Relative humidity: <90% around the no vibration, no corrosive media |
Product Name: Handheld surface roughness tester
Type: NDT120
Handheld surface roughness parameters given NDT120 conform GB / T 3505-2000 "predicate, definitions and parameters Geometrical Product Specifications Surface texture surface structure contour method", in line with GB / T 6062-2002 "Geometrical Product specification (GPS) surface texture profile method of contact (stylus) instruments nominal characteristics. "
Scope: metal and non-metal parts of the surface roughness of the test to detect for a variety of machined parts, machinery processing and manufacturing, testing, inspection and other departments, especially for large parts and production lines of the site inspection, and testing, measurement, inspection and other departments to go out test, will not damage the workpiece. Measurable workpiece: OTHER shaped surface plane, cylindrical surface, conical, bore, groove, surfaces, and (with suitable sensor)
Unique features: rigorous temperature and humidity test, high temperature and high humidity environment adaptation, especially in the southern humid climates measured values are not affected. High precision, stable measurement values, China's leading quality!
