400V 1000UF Aluminum Electrolytic Capacitor Generator Engine Components AC Motor Capacitor

Dongguan City Gonghe Electronic Co., Ltd. Gold Verified Supplier

5Yrs

US$ 0.02 - 200 MOQ: 16 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

GHC

Model Number:

400V 1000UF Aluminum Electrolytic Capacitor Generator Engine Component

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name GHC

Model Number 400V 1000UF Aluminum Electrolytic Capacitor Generator Engine Component

Type Aluminum Electrolytic Capacitor

Application Power

Package Type Through Hole

Capacitance 0.1uF~2,000,000uF

Rated Voltage 4V~630V

Operating Temperature -55℃~+135℃

400V 1000UF Aluminum Electrolytic Capacitor Generator Engine Components AC Motor Capacitor

others:

1.sell on credit accepted

2. with CE,UL,ROHS,ISO9000 certification

3. minimum order accepted

4.excellent after-sell service

widely used in UPS, inverter,electric car,microwave,motor start,elevator,air conditioner,

air compressor,washing machine,cosmetology equipment,main-board, power control system,

energy-saving lamps,digital camera,laser equipment and so on.

Items	Characteristics
Operating Temperature(°C)	-55~135°C
Rated Voltage Range (V.DC)	4~630VDC
Capacitance Tolerance	±20%(20°C, 120Hz)
Leakage Current	I less than 0.02CV OR 5mA (take the minimum)(apply rated voltage for 5 minutes)
Leakage Current	I: leakage current(A) C: rated capacitance V: rated voltage
Temperature Characteristics	Electrostatic Capacitance Range: c(-25°C)/C(+20°C) more than 0.7(120Hz)
Endurance	The following specification shall be satisfied when the rated voltage is applied for 2,000 hours at 85°C
	Capacitance change: ±20% of the initial value
	Dissipation factor(tan Ö): less than 200% of the initial specification value
	Leakage current: less than initial specification value
High-temperature storage	The following specifications shall be satisfied when the capacitor is stored for 500 hours at 85°C and be cooled down to 20°C and was handled according to the JIS C51024.4 term
	Capacitance change rate: ±20% of the initial testing value
	Dissipation factor(tan Ö): less than initial specification value
