240w Poly Solar Panel

240w Poly Solar Panel thumbnail-1
240w Poly Solar Panel photo-1
US$ 0.46 - 0.55 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
OSDA
Model Number:
ODA240-30-P
Contact Supplier Request Quote Chat Now
Ningbo Osda Solar Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name OSDA
Model Number ODA240-30-P
Specification Normal
Application Commercial
Output Voltage (V) 30V
Load Power (W) 240W
Solar Power (W) 240W

Specifications

* 10 years warranty on product materials and processing technology
* Power output warranty: 10 years: 90%, 25years: 80%

Technical parameter(with tolerance 0 to +3%)
Maximum Power(W) 220Wp 225Wp 230Wp 235Wp 240Wp 245Wp
Optimum Power Voltage(Vmp)                                       29.88V 29.94V 29.94V 30.6V 30.6V 30.72V
Optimum Operating Current(Imp) 7.36A 7.52A 7.68A 7.68A 7.84A 7.98A
Open Circuit Voltage(Voc) 36.44V 36.51V 36.51V 37.32V 37.32V 37.46V
Short Circuit Current(Isc) 8.09A 8.26A 8.44A 8.44A 8.62A 8.76A
Cell Efficiency (% ) : 15.50% 15.75% 16.00% :16.50% 17.00% 17.25%
Module Efficiency (%) 13.44% 13.74% 14.10% 14.40% 14.70% 15.10%
Mechanical Characteristics
Cell Type Polycrystalline 156x156mm (6inch)
No of Cell 60(6x10)
Dimensions 1640X992X45
Weight 19.3kgs
Front Glass 3.2mm,High Transmission, Low Iron,Tempered Glass
Frame Anodized Aluminium Alloy
Junction box IP65 Rated
Output Cable TUV 1x4.0mm2/UL12AWG,Length:900mm



Temperature and Coefficients
Operating Temperature(°C):                                           -40°C ~ +   85°C
Maximum System Voltage:                                         600V(UL)/1000V(IEC) DC
Maximum Rated Current Series:                                         15A
Temperature Coefficients of Pmax:                                   -0.47%
Temperature Coefficients of Voc:                                     -0.389%
Temperature Coefficients of Isc:                                       0.057%
Nominal Operationg Cell Temperature (NOCT):                   47+/-2°C
