2x2.5mm2 Solar Cable TUV Solar Panel Wire Tinned Copper 2PfG Multicores solar Cable
- 20000 Meter / Meters per Month
- SHANGHAI/NINGBO PORT
- T/T Credit Card
You May Like
-
Flexible Stranded Tinned CCA Conductor Cable PV1-F Wire Multicores Solar PV Cable
-
VDE standard rubber sheathed cable copper H07RN-F 3x2.5mm2 cable
-
VDE standard rubber sheath cable copper H07RN-F 3x4.0mm2 cable with copetitive price
-
450/750V EPR Rubber cable H07RN-F 2x1mm2 power cable made in china
-
New design H05V-R/H05V-K 16mm2 building wire Pvc coated Electric wire
-
NATURAL RUBBER INSULATED & SHEATHED HO7RN-F 3X1.5MM2 CABLE COPPER FLEXIBLE CABLE
Product Details
| Place of Origin | Zhejiang, China | Brand Name | OEM | |
| Model Number | PV cable | Insulation Material | XLPE | |
| Type | Low Voltage | Application | Other, Photovoltaic power system, Photovoltaic power system | |
| Conductor Material | Other, copper or tinned copper | Jacket | Other, XLPE |
Product Description
CONTRUCTION :
Jacket:XLPE(black)Halogen-free,UV resistant
Insulation:XLPE(black)Halogen-free
PART NO
Black:CA104B-PE Red:CA104R-PE
SPECIFICATIONS:
conduct material :High resistant oxygen copper,Tinned planted
| type | cross scction | wire struct | conductor diameter | outer diameter | conductor resistance | rated voltage | rated current |
| mm2 | NO.OD(mm) | mm | mm | Ω /Km | V AC/DC | A | |
| 1X1.5mm2 | 1.5 | 30x0.25 | 1.6 | 4.5 | 13.9 | 1000/1800 | 20 |
| 1X2.5mm2 | 2.5 | 48x0.25 | 2 | 5.3 | 8.06 | 1000/1800 | 30 |
| 1x4.0mm2 | 4 | 56x0.30 | 2.6 | 6.4 | 4.97 | 1000/1800 | 50 |
| 1x6.0mm2 | 6 | 81x0.30 | 3.3 | 7.2 | 3.52 | 1000/1800 | 70 |
| 1x10.0mm2 | 10 | 74x0.40 | 4.4 | 8.3 | 2.12 | 1000/1800 | 95 |
type | cross setion | wire struct | conductor diameter | outer diameter | conductor resistance | rated voltage | rated current | weight |
| mm2 | NO.OD(MM) | mm | mm | Ω /Km | V AC/DC | A | kg/km |
2x1.5mm2 | 1.5 | 30X0.25 | 1.6 | 5.1*10.2 | 13.9 | 1000/1800 | 30 | 66 |
2x2.5mm2 | 2.5 | 48X0.25 | 2 | 5.4*10.9 | 8.06 | 1000/1800 | 40 | 85 |
2x4.0mm2 | 4.0 | 56X0.30 | 2.6 | 6.2*12.5 | 4.97 | 1000/1800 | 55 | 140 |
2x6.0mm2 | 6.0 | 81X0.30 | 3.3 | 7.1*14.3 | 3.12 | 1000/1800 | 70 | 200 |
Physical properties:
1.Rated voltage:AC 1KV,DC1.8KV
ductor temperature:+120℃
3.Ambient temperature:-40℃- +90℃
4.Max.short circuit temp:+280℃/5S
5.Expected period of use>=25 years;
6.The smallest permissible bending radious:5xouter diameter
Standard:
According to:2PfG 1169/08.2007
Smoke densty:acc. to IEC 61034(EN-50268)
Halogen free .to IEC 60754(EN-50267)
Ozone resistance:acc to IEC 60811
UV resistant:HD605/A1
1We are a factory dedicating and manufacturing audio drivr, best production and technology capability, best quality control, Best Service.
2.100% QC inspection before Shippment
3.We offer flexible payment terms,L/C at sight,T/T,west union etc.
4.We accept the small quantity and OEM service can be offered.
5.All the order we promise the guarantee and two weeks lead time.
JIAXING HUAHAO CABLE CO.,LTD is located in ZHEJINAG provnce
