Specifications
1. Multiplexer with 8 TS in and 2 TS out2. stable performance
3.NMS control
Outline
NDS3101 single output multiplexer is an enhanced TS multiplexer for digital TV broadcasting head-end system. It can multiplex up to 8 channels ASI input MPTS into one output transport stream (MPTS). The multiplexer also can insert EPG (electronic program guide), CA (conditional access), data broadcasting into output TS. This multiplexer has the functions of supporting auto-generation of PSI/SI information, PID re-mapping, service filtering and PSI/SI editing. The bit rate of input stream can reach up to 216Mbps, while the bit rate of output stream can reach 108Mbps. Furthermore, the NDS3101 multiplexer is provided with half size LCD display and a 100M/10M Ethernet port for network management. Therefore, user can easily configure the settings of the device.
Features
- Fully complying with ISO13818 and EN300468
- Support 1channel TS re-multiplexing
- 8 ASI input ports
- 1 multiplexing ASI output,maximum code rate up to 108Mbps
- Support accurate PCR adjusting
- Support PSI/SI rebuilding and editing
- extracting PSI/SI information from any route of SPTS/MPTS inputs
- Supporting the cascading connection between multiple equipments.
- LCD/keyboard and network management(NMS)
Specifications
Input Interface |
ASI |
8 ASI input ports |
Re-multiplexing |
1 channel TS stream re-multiplexing |
|
PID Remapping | ||
PCR accurate adjusting | ||
Automatically Generating PSI/SI Table | ||
Output Interface |
ASI |
One multiplexing output ports (1X2 ASI out, one as mirror) |
NMS Interface |
Ethernet port |
10/100Mbps NMS Ethernet Port |
Miscellaneous |
Dimension |
44mm´482mm´360mm |
Environment |
0~45°C(Operation);-20~80(Storage) |
|
Power |
110VAC±10%,50/60Hz 220VAC±10%,50/60Hz |
|
power |
220VAC±10%,50Hz |
|
Consumption |
25W |
|
