Help CenterSCRAMBLER EMBEDDED 8 in 2 IP Multiplexer
Related Products
Specifications
1.8 ASI in , 8 ASI out , IP out2. multipler and scrambler all in one
3.Maximum support simulcrypt CA -4
Outline
NDS3712A Mux Scrambler is a new high integrated device for CATV head end broadcasting system. It has equipped with 8 ASI input, after multiplexing and scrambling then output TS by four ASI interface (2 independent output group) and one RJ45 port. Furthermore, it supports UDP IP out uncast and multicast.
Feature
l Module design, 8 channels input interface for user to combine randomly(optional ASI or tuner input)
l Fully support DVB general scrambling system description ETR289, ETSI 101 197 and ETSI 103 197 simulcrypt standards.
l Support TS over UDP protocol, unicast and multicast, IGMP V2/V3
l Multiplex the input TS and output through two channels.
l Support multiplexing casual TS from input and output. Maximum 256 PID remapping of each channel.
l Support PCR accurate adjusting
l GE port supports 1 Gbps data output channel
l Support PSI/SI editing and inserting
l Support two channels scrambling simultaneously. Each scrambling channel support 4 simulcrypt CA
l Support NMS(network management system)
l Support LCD panel management
Specification
Input interface |
8 BNC interface |
|||
Multiplexer |
Input channel |
8 channels ASI input |
||
Output channel |
2 groups of standalone ASI output and 2 corresponding IP output |
|||
Maximum PID remapping |
256 per input channel |
|||
Function |
PID remapping(automatically or manually) |
|||
PCR accurate adjusting | ||||
Generate PSI/SI table automatically | ||||
|
|
|||
Scrambling parameters |
Maximum support simulcrypt CA |
4 |
||
Standard |
ETSI 101 197,ETSI 103 197 |
|||
Way of Connection |
Local/Remote connect |
|||
IP output |
Interface |
RJ45 |
||
Output Protocol |
TS over UDP protocol |
|||
Output Bit-rate |
1-108Mbps per output channel |
|||
ASI output |
Interface |
4 BNC interface |
||
Output form |
TS |
|||
Output bit-rate |
1-108Mbps per output channel |
|||
System |
Support NMS and LCD panel management |
|||
|
General
|
Demission (W x L x H) |
482mm×455mm×44.5mm |
||
Weight |
2.5kg |
|||
Temperature |
0~45°C(operation),-20~80°C(storage) |
|||
Power supply |
AC 110V±10%,50/60Hz Or AC 220V±10%,50/60Hz |
|||
Consumption |
≈15.4W |
|||
