API Tube

US$ 500 - 2,000 MOQ: 50 Tons

Key Specifications

Standard:

Grade:

Thickness:

1, 150

Shaoxing Shangyu Baomingjia Metal Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Thickness 1, 150

Section Shape Round

Outer Diameter 21.3 - 914 mm, 21.3 -914 mm

Place of Origin Zhejiang, China

Secondary Or Not Non-secondary

Application Other, Boiler Pipe, Gas pipe/Oil pipe/Fluid ect

Certification Other, API, API

Surface Treatment Other, Galvanized, 3PE painting

Special Pipe Thick Wall Pipe

Alloy Or Not Non-alloy

Specifications

API tube
1.Environmental protection,
2.beautiful appearance,
3.strong and durable,
4.acid an

Product name:API tube

Specifications:

Thickness	1-150mm
Length	Less than12m
Outer Diameter	21.3 -914 mm
Material	Q195 → Grade B, SS330,SPHC, S185 Q215 → Grade C,CS Type B,SS330, SPHC Q235 → Grade D,SS400,S235JR,S235JO,S235J2 Q345 → SS500,ST52 X42--X70
Standard	ASTM A106-B ,ASTM A53-B, API 5L-B, API 5L, X42, X52, J55 , SAE1020, SAE1045, DIN 17175 ST 35.8,ST37,ST45,DIN2391 ST52 (16Mn)
Technique	SWA, hot rolled .or cold rolled,
Certification	API
Surface	Bare, Varnished, Zinc coating, Anti-corrosion, 3PE, PE/PP/EP/FBE. etc.
Ends	Plain, bevelled and capped as well
Application	Natural gas, petroleum, chemical industry, electric power, metallurgy thermodynamic fields, water supply engineering, steam heating
Packaging Details	Standard export packing or according to the clients required

Mechanical Properties:

Classification & Application:

Product	Standard		Steel Grade	Application
Line Pipe		API 5L, ASTM A53/A106, DIN1629, JIS G3454, JIS3466	A, B, X42, X46, X52, X56, X60, X65, X70, St37,ST52	Transmission of the petroleum, natural gas and water
Cylinder Pipe		GB18248	34Mn2V, 37Mn, 30CrMo, 34CrMo4	Raw material for producing cylinder
Boiler Tube		ASME SA106, ASME SA210, ASME SA213, ASME SA335, DIN 17175, GB3087, GB5310	A, B, V, T11, T12, T22, T91, St35.8, St45.8, 20#, 20G, 20MnG, 20MoG, 15CrMoG, 12Cr1MoVG	Low & medium & high pressure boiler header, steam pipe, heating pipe
Structure Pipe		ASTM A53/A106, GB8162	A, B, 20#, 45#, Q345, 20Mn2, 42CrMo	Used for producing mechanical parts and pipe fittings
Hydraulic Tube		GB17396	35#, 45#, 27SiMn, 20CrMo4, 30CrMo4	Mining machinery
Oil Cracking Tube		ASME SA213, GB9948	T5, T9, 20#, 16Mn, 12CrMo, 15CrMo	Used in petroleum cracking furnace
Chemical Pipe		GB6479	20#, 16Mn, 12CrMo, 15CrMo	High pressure chemical equipment and tube
