ZLPG Series Spray Dryer Of Chinese Traditional Medicine Extract

ZLPG Series Spray Dryer Of Chinese Traditional Medicine Extract thumbnail-1
ZLPG Series Spray Dryer Of Chinese Traditional Medicine Extract photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Spray Drying Equipment
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Changzhou Yeping Drying Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Spray Drying Equipment
Place of Origin Jiangsu, China
Brand Name YEPING
Model Number ZLPG5-300
Voltage 220V-440V
Power(W) 63-330kw
Dimension(L*W*H) 7000*4000*5200-15000*9000*11100
Weight 1-20t
Certification CE,HACCP,ISO9001,
Warranty 1 years
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ZLPG Spray Dryer
1Much more better than normal spray dryer
2Chinese herbal medicine
3High effect
4 Low pullution

ZLPG Series Spray Dryer Of Chinese Traditional Medicine Extract

ZLPG Series Spray Dryer Of Chinese Traditional Medicine Extract



Product Description



Description of Products

The machine adapts full seal form. All parts are made of stainless steel. It is equipped with three grades of purifying apparatus. The filtered air reaches the requirement of one hundred thousand grades. The cooling appetites of wall is installed at the cylinder body and top.It makes the wall temperature less than 80°C, Air sweeping device is installed inside the drying tower. The dried immrsedointment powder of traditional Chinese medicinecan not appear the phenomenon of carbonization and degeneration. The ratio of received powder is raised greatly. Moreover it can not produce the phenomenon of medicine mixing and wall staying.
Basic principle: high-speed centrifuge atomizing application of centrifuge atomizing drier.
1.Raw material is attached to wall and the ratio of received powder is low;
2.Because the staying time of raw material at wall is long, the phenomenon of carbonization and degeneration can be produced;
3.It is different to clean and can not meet the requirement of GMP;
4.Low in output: Model LPG-150 atomizing centrifuge drier can process 50-60 kg/h of raw material liquid.
In view of this, according to the properties and process requirements of immersed ointment of the properties and process requirements of immersed ointment of traditional Chinese medicine. Our factory researvhed and designed the special drier for immersed ointment of traditional Chinese medicine and won two items of china patent. It solves. The historical difficult problems in drying immersed ointment of traditional Chinese medicine. The color of dried raw material is good. The dried raw material does not degenerate. It raised the economic benefit greatly. Compared with original LPG high-speed atomizing drier, it has the following features;
1.Being adapted three-grade air purification, the inlet air reaches the requirement of one hundred thousand grade;
2.Being adapted wall cooling device, the temperature of inner wall will be 80°C, Even if raw material is stayed on the wall , it can not carbonize;
3.Its whole volume is 3.5 times of standard LPG high-speed atomizing drier;
4.Being adapted quick washing device, it is can meet the requirements of production for varieties products;
5.Being adapted air sweeping device, the clean effect is satisfied;
6.Being adapted air sweeping device, the clean effect is satisfied;
7.Equipped two sets of atomizer and adapted frequency control;
8.Adapted two sets of atomizer and adapted trequency control;
9.Equipped with washing device;
10.Adapted the seal method to transport dry air.



Tower body has jacket of cool air;
*Tower body is equipped with automatic vibration and being device;
*Tower body and pipe line have cleaning hole and swage dis-charge hole that can open quickly;
*Thermostat ending tank;
*Accompanied parts of high press use washing tower;
*The parts that can contact with raw material are mead of stain-less steel fully;
*The collecting of raw material adapts two grade cyclone duster or one-grade cyclone duster and one-grade damp duster.
*The temperature of inlet air can be controlled automatically and continuously;
*Equipped with air sweeping device.



Model

ZLPG-13

ZLPG-17

ZLPG-25

ZLPG-32

ZLPG-38

ZLPG-40

ZLPG-47

ZLPG-52

ZLPG-58

Water Evaporation (kg/h)

5

10

25

50

80

100

150

200

300

Treated Liquid Feed (kg/h)

6-7

12-14

25-34

50-68

80-108

100-135

150-203

200-270

300-406

Finished Product (kg/h)

1-2

2-4

4.8-7.2

9.2-14

14.5-22.4

18.4-28

28-42

36.8-56.4

55-85

Solid Content in Wet Material (%)

18-25

Product Water Content (%)

3-5

Power (kw)

36

45

63

99

132

153

204

246

330

Power and Heat Source

Steam plus Electricity

Product Collecting Method and Its Power

Two-grade cyclone duster and one-grade cyclone duster and one-grade wet duster≥95%

Automatic Instruments

Indicator of temperature of hot air and discharge air, automatic temperature controller

Inlet Air Temperature (°C)

150-200

Outlet Air Temperature (°C)

80-100

Size (mm)

l

5000

5500

7000

8000

9800

11000

12200

14100

15000

w

3000

3500

4000

5000

5700

6200

7000

7800

9000

h

4500

4600

5200

6500

7600

8100

9000

9850





Our Services

 1.Accept OEM service



2.Engineers available to service machinery overseas
3.Our products including:Spray drying machine,drying oven,flash vaporization dryer,Meshbelt dryer,Vibrating-fliudized Dryer,etc.
4. we are able to cater to all the required expectations of our valued clients .
 Why Choose Us?
1.We are professional drying equipment manufature in china,has excellent experience.
2.We have advanced machine equipment, cost savings.
3.We supply 24 hours online service to slove your every question.
4.We have the best knowledge about the drying machine in USA,UK,CANADA,SOUTH AFRICA,INDIA,AUSTRALIA,ETC.
Welcome you to contact us no hesitation!!!!
