VHJ Series Mixing MachineThe machine is suitable for pharmaceutical, chemical, food dry powder, granule materials of mixed in
VHJ Series Mixing Machine
1. Purpose, principles
The machine is suitable for pharmaceutical, chemical, food dry powder, granule materials of mixed in.
This machine mixing tube structure is unique, with high efficiency, no dead Angle, made of stainless steel, internal and external wall polishing treatment, beautiful shape, mixing, applicable wider, and can according to the requirements of the customers supporting forced mixer, in order to suit the fine powder, block and with certain water content material mix. Product features mixing tube structure is unique, mixed with high efficiency, no dead Angle, barrel with stainless steel material production, internal and external wall polishing, beautiful shape, mixing, used widely. In accordance with GMP standard.
2. Product features
Mixing tube structure is unique, mixed with high efficiency, no dead Angle, barrel with stainless
steel material production, internal and external wall polishing, beautiful shape, mixing, used widely. In accordance with GMP standard.
3.Technical parameters
|
Type |
load |
motor power (kw) |
maximum diameter (mm) |
totall height (mm) |
machine weight (kg) |
|
VH-0.2 |
0.4-0.6 |
2.2 |
890 |
1850 |
600 |
|
VH-0.5 |
0.4-0.6 |
3 |
1160 |
2250 |
600 |
|
VH -1 |
0.4-0.6 |
4 |
1450 |
2700 |
1200 |
|
VH -2 |
0.4-0.6 |
5.5 |
1850 |
3450 |
1800 |
|
VH -4 |
0.4-0.6 |
11 |
2260 |
4210 |
3000 |
|
VH -6 |
0.4-0.6 |
15 |
2715 |
4382 |
3500 |
1.Accept OEM service
2.Engineers available to service machinery overseas
