High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station:
How hard is hard? The illustrations shown below tell an interesting story. Illustration ‘A’ shows an analysis of the cross sectional hardness of The Steel Ball Company’s ‘thru hard’ ball. Illustration ‘B’ below shows the same analysis carried out on a ball from another major grinding media manufacturer. The ball in illustration ‘B’ has the same AVH figure as The Steel Ball Company’s ball and will wear out at the same time. Yet there the similarity ends. After three quarters of the radius, the hardness of the ‘B’ ball dips below that of The Steel Ball Company’s ball. This brings into focus the area of greatest discussion about using AVH values. Over 72% of the final value is made up from the surface and 3/4 radius hardness readings. So AVH tells us relatively little about how a ball is going to perform once it has worn past that stage.
The cross sectional hardness profile tells the full ‘inside story’.
Q What kind of performance will the ball in illustration ‘B’ below give?
A Once the ball has worn down to approximately 2/3 diameter, the remainder will wear away very quickly.
Q How will this affect the mill output?
A The rapidly wearing grinding media will give rise to an unstable and imbalanced ball charge, resulting in the possibility of more than one top up size being required to ensure the correct mesh of grind.
Q How will The Steel Ball Company’s ball perform?
A The cross sectional hardness profile shows that The Steel Ball Company’s ‘thru hard’ ball will wear evenly throughout its life. This will give a better size distribution in the mill, and avoid ‘dead zone grinding’. The shape of the ball will be preserved for much longer, giving a far more efficient grind. The conclusions are obvious. High quality such as The Steel Ball Company offers always saves money in the long run. AVH =0.289 x Surface Hardness (S) + 0.437 x Hardness 3/4 R + 0.203xHardness 1/2 R + 0.063 x Hardness 1/4R + 0.008 x Centre Hardness (C)
As one of the leading grinding balls specialists in China, we can certainly assist you in buying all kinds of grinding balls that suit your company needs. Our yearly production capacity in about 200000 Ton. We own an integrated set of advanced import production line, so that you can be satisfied with the quality of our products.
Feature of High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station
1) In general, grinding steel ball has high hardness: surface hardness to 58-65 HRC, volume hardness of 56-65 HRC
2) impact toughness high: impact toughness more than 12 J / cm2.
3) broken rate is low: the actual broken rate is not higher than 0.5%.
4) loss of grinding forged steel ball round rate is low.
Chemical Composition of High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station
Brand |
C |
Mn |
Si |
Cr |
S |
P |
V |
1A |
0.37-0.55 |
0.50-1.0 |
0.17-0.47 |
0.80-1.2 |
≤0.035 |
≤0.035 |
|
2A |
0.7-1.00 |
0.7-1.0 |
≤0.025 |
0.4-0.8 |
≤0.025 |
≤0.025 |
|
3A |
0.45-0.65 |
0.7-0.8 |
1.5-1.8 |
0.77-1.0 |
≤0.006 |
≤0.025 |
|
45 |
0.40-0.55 |
0.50-0.85 |
0.71-0.47 |
≤0.25 |
≤0.025 |
≤0.025 |
|
65 |
0.55-0.70 |
0.80-1.25 |
0.17-0.47 |
≤0.25 |
≤0.035 |
≤0.035 |
|
Hardness of High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station
|
1A |
2A |
3A |
45 |
65 |
Superficial |
>60HRC |
>60HRC |
>60HRC |
>58HRC |
>60HRC |
Volumetric |
>58HRC |
>60HRC |
>60HRC |
>55HRC |
>60HRC |
Assurance & Testing Forged Steel Grinding Ball apply for High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station
*The each melt will be analyzed for Chemical Composition;
*The hardness will be measured on 5 balls selected at random from each heat treatment batch;
*Two ball at least will be selected randomly from each heat treatment batch for micro-examination;
*The diameter test and all the above mentioned test will be showed and carried out on the templates;
* Sand and Slag inclusion will not existed ;
* Depth of defect is more than 2mm will not existed;
* Mismatch per face is more than 1.0mm will not existed ;
* All casting balls will be properly fettled,tumbled and dressed,all surface shall be thoroughly cleaned .
Instructions of High Hardness Steel Grinding Ball with High Hardness Used for Mine & Cement Plant & Power Station:
When using CMAX products,please pay attention to the following items:
1.Due to different inner structures and hardness of similar products made by different companies, please don’t mix our products with those of other companies,or it will be subject to deformation.
2.Please control the grain size of raw materials and the proportion of grinding materials to grinding
medias.Unreasonable proportion is bad for the use of our products.
3.When using the products,please do not pursue product fineness at the cost of reducing the output .
Otherwise ,our products will be exfoliated and out of shape.
4.In the process of using our products,the mill could not be opened or stopped frequently,or operated
without any materials in it.Before putting the casting balls into the container,please put some materials
in the lowest floor in case of breakage, clashing and so on.
5.Open the door of the mill at first and pour the balls out when the temperature in the mill falls down .
6.If you find something unusual in the process of using,please contact us immediately and we will arrive on the spot as soon as possible.8
0mm Cast Steel Grinding Balls
Company information:
CNBM International Corporation, as one of the largest manufacturer of grinding balls and also the affiliated company of CNBM Group, which has list as one of the 500 Global Fortune 500 companies since 2011 to 2014.
Using high quality special steel as raw material, the characteristics of our grinding balls are proud of high hardness, well abrasive resistance, non-deformation, low breakage lower than 1%.
We sincerely welcome partners all over the world to establish long business cooperation with us on the basis of mutual trust, benefit and development.
