Help CenterArc Stud Welding Shear Connectors With Ceramic Ferrules for Steel Structures
Related Products
-
Stud Welding Shear ConnectorsNegotiableMOQ: 1 Metric Ton -
Shear Connectors/bolts From CNBMNegotiableMOQ: 1 Metric Ton
-
New Design Binding Iron Wire With CE CertificateNegotiableMOQ: 20 Tons
-
Brand New Binding Iron Wire With Great PriceNegotiableMOQ: 20 Tons
-
Galvanised Wire Binding Iron Wire With Low PriceNegotiableMOQ: 20 Tons
Shear Connector Studs are designed to tie the concrete to the steel beams and to resist shear loadings
between the concrete slab and steel beam in composite construction.
Shear connectors on the top flanges of the steel girders provide the means to achieve composite action between the slab and the girders, thus increasing both stiffness and strength.
Shear studs are used in stud welding to secure steel framed buildings to create a shear connection between the steel and the concrete. We supply and fix all available sizes of welded shear studs for through deck and straight to steel welding.
Shear connector standards or specs:
GB/T 10433,ASTM A108,ASW D1.1,EN ISO13918,AS/NZS1554,JIS B1198
Shear connector/shear stud introduction:
Description |
Shear connectors, shear studs, welding studs |
Materials |
Carbon steel or stainless steel |
Available specs |
GB/T 10433,ASTM A108,ASW D1.1,EN ISO13918,AS/NZS1554,JIS B1198 |
Dia |
M12-M25(1/2”-1”) |
Length |
50-300MM(2”-11-3/4”) |
Head mark |
HYZ or customized |
Used |
Steel structures such as bridge construction, airport, railway, multi-floor& high-rise steel structure building,ect |
Mechanical properties for different standard
standard |
Tensile strength |
Yield strength |
Elongation |
ASWD1.1 |
≥450MPA |
≥350MPA |
≥15%/20% |
EN:ISO13918 |
≥450MPA |
≥350MPA |
≥15% |
JIS B1198 |
≥450MPA |
≥235MPA |
≥20 |
Application and project:
All our products are used for steel structure project, such as:
Multi-floor& high-rise steel structure buildings, industrial building (factory or other industry producing room), high way, railway, steel steam, tower, power station, traffic instrument construction, mast structure piping bracket, lift machine, boiler, airport, and other steel structure workshop frame.
Company Information
We are the Chinese state owned and one of the world top 500 enterprises, with SGS approved and ISO9001 certified.
We specialize in supplying:
l Welding stud/Shear connector
l High strength hex head bolt 8.8 /10.9
l High strength tension control bolt /shear bolt 8.8/10.9
l Thread rod
l Stud welding machine
l Other building materials such as steel coils etc
Product show:
