Temperature Sensor Head IP65

Sensor head is widly used in thermocouple and RTD assembly, with function of water proof ,oilproof, explosion-proof and  dustproof for wiring terminal block or transmitter

Feature:

1. Tools are well designed and long life-span make the die-casting running perfect.

2.Modern die-casting machines from 160 tons to 300 tons to fit different models casting request.

3.Different polishing methods for each model's cover and bidy, surface is shining after polishing.

4.Machining and threading strictly conform to threads standard, calibrated by thread gauges.

5.Two types of painting on customers' choice:

-normal lacquer spraying

-Polyester resin powder coating

6.Efficient assembly process and professional packing.

Specification

1) Cover diameter 76mm
2) Ceramic terminal blocks:

    mounting holes distance: 36±0.1mm

3) Probe entry: M12×1, M16×1, M20×1, M22×1, G1/2, NPT1/2

4) Wire entry: M20×1.5, G1/2, NPT1/2

5) Product N.W.: 214g

6) Packing condition: Plastic holder + internal carton(L460×W220×H90mm)

                                + external carton(L470×W460×H300mm), 60pcs/ex-ctn
