Specifications
China Access control full height turnstile
1.turnstile steady
2. precise durable silent
3.CE approved
Security Access Control System
Full Height Turnstile Rotary Turnstile Gate
Features and Functions:
1. Rainproof housing, anti-corrosion coating iron or #304 stainless steel
2. CNC stamping and laser drilling, presenting a novel and elegant appearance 3. Innovative and unique mounting surface ensures simple and convenient installation for system integrators;
4. Direction can be set as single-direction or bi-direction
5. Direction indicator
6. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)
7. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically;
8. With backup battery, complying with fire safety requirements.
9. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact when running.
10. Dual-bearing device, keeping the gate in balance when there is external force
2. Technical Parameters
Model | PD-002c |
Voltage | AC220V/110V10% |
Frequency | 50/60Hz |
Current | 3A |
Controlcircuit: | DC24V |
Power consumption | 40W |
Working temperature | -20C~60C |
Working humidity | 0~95%RH |
Maximum bearing capacity | 80kgs |
Bar length | 550mm |
3. Functions & Features
1) Automatically low noise mechanism core equipped, highly cost-performance
2) Sense positioning, reducing mechanical impact make lifetime longer
3) Operating efficiency, 1~2 seconds open & close
4) Lowest Noise : No matter in operating or outside control, Noise control under 30db
5) Self-checking and Alarm warning for maintain
6) Resetting: System cancel authorized pass if passenger delayed pass
Anti-following : prevent illegal passing
Anti-clamp :The wings will stopped during in external block, the wings reset again after default delay
9) The rotary wings will be locked automatically if the system do not receive IR signal
10) Multi-passage for variety application demands , cover 99% needs on earth
11) Programmable signal separate control : pass time,pass speed etc. parameter
12) RS232/RS485 interface meet all kind of communications or wireless connection
Compatible IC/ID card ,flexible couple
Long-distance management through COMPUTER
15) Customize Options: LED display, Voice guide, Warning Lamps, Indicator Lights guide, Audible &Visible Alarm
4. Control & Interfaces
1, Card readers
2, Metal detection
3, Electronic/LCD counters
4, Fail-open or fail-secure locking
5, Push-button and wireless remotes
6, Manual key override both directions
7, Indicator lights
5. Packaging & Delivery
Packaging Detail: Wooden box
Delivery detail: within 10 working days after payment confirmed
