Help CenterAgricultral Equipment Longitudinal Welded or Spiral Welded Carbon Steel Bridge Slot Screen
Related Products
-
China Factory Steel Pipe Water Filter Water Well ScreenUS$ 10 - 150MOQ: 1 Meter -
Filter Pipe Water Well Bridge Slot Steel PipeUS$ 10 - 150MOQ: 1 Meter
-
Factory Carbon Steel Bridge Slot Pipe for WaterUS$ 10 - 150MOQ: 10 Meters
-
Manufacture BJF Carbon Steel Sand Filter Bridge Slot Well Screen for WaterUS$ 15 - 150MOQ: 12 Meters
-
Longitudinal Welded Galvanized Bridge Slot Screen PipeUS$ 15 - 150MOQ: 10 Meters
Specifications
bridge slot screenlow price
high quality
fast delivery
agricultral equipment longitudinal welded or spiral welded carbon steel bridge slot screen
Bridge slot screen pipes have openings arranged in rows are staggered to reduce the negative effect on the screen’s strength . Typically the slots are punched in a flat sheet that is subsequently rolled into a tube and welded. Regarded as the best choice of well tube filter, bridge slot screens are widely applied in a variety of fields in the developed countries. According to our after-sale services and the application experience at home and abroad, the advantage of bridge slot screens, when compared with other kinds of screens, can be listed as follows:
1.High strength through resistance to twisting, compressive, and tensile forces.
2.A smooth bore that does not impede the passage of probes, tools, etc.
3.The special structure of the slot makes it difficult for particles to get stuck in the slot, thus bettering its discharge capacity.
4.The special bridge slot of screens help improving their mechanical strength.
5.Application of Anticorrosive coasting will prolong the span life of wells.
6.Slots and the diameter of bridge slot screens can be custom made to satisfy your needs.
7.Convenient to operate owing to various connecting methods between screens.
Lighter in weight and lower in price.
outer diameter |
114-600mm |
material |
low carbon steel, stainless steel 304 316 |
thickness |
3-8mm |
Welded |
Longitudinal welded or spiral weled |
PRODUCTION CAPICITY: 10,000 TONS PER YEAR
longitudinal welded bridge slot screen pipe
spiral welded bridge slot screen pipe
Production line
loose package, bundle package, pallet package, container package
Beijing Filter Trade Company Limited, Integrated supplier of drilling engineering industry chain.
Highlight of service and downstream manufacturers:
1. Business range covers the whole industry chain of well drilling, including casing pipe and tube, well screens, drilling rig and pipe, industrial additives, logistics service
2. Professional manufactory
3. Industrialized automatic manufacturing line
4. Export oriented factory
5. Production supplier of large-scale projects, including stadium construction for Olympic Beijing 2008, subway construction in Beijing and Shanghai, government procurement for Africa reconstruction, etc.
Customized design and manufacture
OEM service
Business range:
1. continuous slot wire wrap screen, pipe base screen, perforated pipe, slotted pipe
2. API casing pipe and tube
3. stainless steel pipe
3. drilling rig, mud pump, air compressor and accessories
4. test instrument
5. welding machine
6. food and beverage
7. industrial additives
Application
The available projects we are serving as follows: Development of water resources, Development of geothermal energy, Groundwater monitoring, Water diversion project, City water supply, Agricultural irrigation, City waste water treatment, subway construction dewatering, Desalination of sea water, Coal mine dewatering, Chemical and Beverage processing machinery.
