Tollar AHD 960p MODULE CAMERA BOARD with 1/3 "AR0130 CMOS sensor for HD analog camera
Specifications |
TL-AHD-AR0130 |
Sensor |
1/3 "AR0130 CMOS sensor; |
Resolution |
PAL/NTSC : AHD-M Definition (TVL) is equivalent to the Network HD 960P Camera |
Illumination |
Color:0.01Lux@(F1.2,AGC ON),0Lux with IR |
B&W:0.001Lux@(F1.2,AGC ON),0Lux with IR | |
Photoresistor mouth |
A photoresistor interface, support photoresistor input, IR-CUT, infrared light linkage |
Shutter Mode |
1/50 (1/60) sec to 1 / 100,000 sec. |
Day &Night |
Support IR-CUT mechanical switch |
Lens parameters |
C / CS interface, M12 lens options |
Synchronous mode |
Internal Synchronization |
SNR |
>45dB |
Frame accumulation |
Support (maximum 30) |
DNR |
2DNR,3DNR |
Business function |
MOTION,PRIVACY,DEFOG,MIRROR,RS485 |
D-WDR |
support |
BACKLIGHT |
BLC,HSBLC |
CVBSsignal |
Support for a key switch CVBS signal,1000TVL |
Power supply |
DC12V±10% |
Power |
<5W |
Working temperature and humidity |
10℃ ~ 60℃,Humidity less than 90% (non-condensing) |
Size |
32mm*32mm/38mm*38mm |
Netural Hardboard box outside with air pocket for each one,for the box,we can design and print as your requirement.
first,you can take the sample from our aliexpress to order,for the large quantity,you can email or call me online,i'll give you more clear picture and lowest price.
Normal Package:
25pcs in a pallet;
500pcs in a carton, Size: 30*30*37CM Weight: 6.5kgs.
Delivery Time:
A: We can supply from stock for samples;
B: Within 3 working days for 1000pcs ordered quantity;
C: Within 1week for 5000pcs ordered quantity;
D: Within 12 working days for 10,000 ordered quantity.
Warranty:
2-years long time warranty, life time maintain !
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery term:
By Express(DHL/FEDEX/TNT/UPS/EMS).By Air ,By Sea.
tollar security equipment co.,ltd is one of the fast growing cctv manufactures in china,We are a modernized Hi-tech enterprise that specializes in developing high quality security products,combining both manufacturing and sales.
We deal in all kinds of CCTV cameras such as camera module,different types analog cameras,HD-Analog(CVI,AHD,TVI),IP,PTZ Speed Dome camera,dvr,nvr knit etc cameras,all our products have been certified by CE,FCC,ROHS.
Now our products have been successfully exported to over 100 countries,obtained full OEM/ODM experience,gained huge share of the market and popularity.we have more than 100 skilled workers are able to produce 30,000pcs of high-Quality CCTV camera and more than 100,000pcs chipset monthly.
We wish to serve different levels of organizations and customers in all kinds of sectors and make our best effort to meet clients' satisfaction.
TOLLAR is a production of CCTV chipboard sales of the manufacturer, its products cover : Original SONY CCD, CMOS, LG, Nextchip,SDI ... ect.
Also, we can well customize the products as per our clients' requests.
Welcome OEM & ODM orders !
For more details or best price, welcome to contact with Sunny at any time !!!
Many thanks for your greatest support!!!
Q: How long is the warranty?
A: 2 -years-warranty since delivered out.
Q: What's the MOQ?
A: 1pc for sampe, at least 10pcs after sample order.
Q: How long is the delivery time?
A: Sample order 3-5 working days, bulk order 7-15 working days.
Q: Why do you choose us?
A: Choose Tollar vision Co., Ltd; Choose a qualified CCTV Products manufacturer!
We will try our best to find the products you need, we will provide you with the most satisfactory service. If you want to know more, You can contact us. We also welcome you to visit our factory in Shenzhen.
PLS ADD MY SKYPE:tanya199255
