Home > Products > Printed Circuit Board > FR4 Elevator PCB Board
FR4 Elevator PCB Board
- 4000 Square Meter / Square Meters per Month
- Shenzhen Hongkong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Rigao PCB | |
| Model Number | Rigao PCB-023 | Base Material | FR-4 | |
| Copper Thickness | 1 oz | Board Thickness | 1.6 mm | |
| Min. Hole Size | 0.25mm | Min. Line Width | 0.12mm | |
| Min. Line Spacing | 0.12mm | Surface Finishing | HSAL lead free |
Product Description
Specifications
FR4 Elevator PCB Board;No MOQ;
OEM SMT&DIP Service;
1-22 Layer;
UL.ROSH SGS Certification.
Welcome To Rigao Electronics
FR4 Elevator PCB Board
- Contract Manufacturing
- Engineering Services
- PCB Design & Assembly and copy service
- Prototyping
- Components purchasing
- Cable and Wire Assemblies
- Plastics and Molds
- Fast turn around
General Specifications Capability
Material Requirements:
| Size | Max.Finshed Size | 20.9”x24.4”(530mm x 620mm ) |
| Board Thickness | Standard | 0.004”to0.16 ” ±10% ( 0.1mmto4.0mm±10% ) |
| Min. | Single/ Double-sided:0.008”±0.004”(0.2mm ±0.1mm) | |
| 4-layer:0.01”±0.008”(0.4mm ±0.1mm) | ||
| 8-layer :0.01”±0.008”(0.4mm ±0.1mm) | ||
| Bow and twist | < 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5oz ~ 3.0oz |
| Inner Cu wight | 0.5oz ~ 3.0oz | |
| Laminate Materials | FR-4,FR-1,,FR-2,CEM-1,CEM-3 | |
Process Requirements:
| Solder Mask | Color | green,light green,white,black,dark brown,yellow,red,blue |
| Min. solder mask clearance | 0.003”(0.07mm) | |
| Thickness | 0.0005”-0.0007”(0.012mm-0.017mm) | |
| Silkscreen | Color | White,black,yellow,red,blue,green |
| Min. Size | 0.006”(0.15mm) | |
| Surface Finish | HASL,HASL pb free,immersion gold,immersion silver,immersion tin,O.S.P (Entek),S/G plating,ENEPIG,G/F plating,carbon | |
Quality Control:
| Electrical testing | Flying Probe Tester | Y |
| Controlled Impedance | Tolerance | ±10% |
| Impedance tester | Tektronix TDS8200 | |
| Routing | End Mills Test | ± 0.006”(0.15mm) |
| CNC Tolerance | ±0.004”(0.1mm) | |
| V-Cut Depth V-cut | FR-4(1/3+-0.1mm);FR-1,FR-2,CEM-1,CEM-3(1/2+-0.1mm) | |
| V-cut angle V-CUT | 15°,18°,30° | |
| V-CUT | line,hole,V-shape |
Certificates:
| UL Cert. | Y |
| ISO Cert. | ISO9001 :2008 |
| TS16949 | Y |
| ISO14000 | Y |
Manufacturing Capability for PCB Board
1). Material type: CEM-3,FR-4,FR-4-TG170/TG180,Halogen Free,Rogers,Arlon,Taconic,Isola,PTFE, Bergquist
2). Surface Treatment: HASL,HASL lead-free,HAL,Flash gold,immersion gold,OSP,Gold Finger Palting,Selective thick gold plating, immersion silver,immersion tin, Carbon ink,peelable mask
3). Solder mask colour: Green/MATT Green/Blue/Yello/White/Black/Red
4). Board Size: 650mm*1000mm
5). Board Layer: 1L-26L
6). Board thickness: 0.2mm to 6.0mm
7). Finished Copper thickness: 0.5 OZ to 6 OZ
8). Min. drilled hole size: 3mil (0.075mm)
9). Min. Line width/Line spacing: 3mil/3mil
10). Copper thickness in hole: >20um
11). Board thickness tolerance: ±10%
12). Outline tolerance: Routing:±0.1mm,Punching:±0.1mm
13). Hole tolerance: PTH: ±0.076mm , NPTH: ±0.05mm
14). impedance control tolerance: ±10%
15). Warp and Twist: <0.75%
16). Tested by:Flying-Probe Tester, Fixture tester , Visual Inspection
17). Special requirements: Buried and blind vias, impedance control, thick Cu PCB,selectivity plating gold 30 microinch
18). Profiling: Punching, Routing, V-CUT, Beveling
19). Certificate: UL,ISO 9001,ISO14001,ROHS
20). We have a sound quality management system,Ensure the quality of all products
High precision manufacturing
Why choose us?
Our manufacturing and quality control processes are ISO 9001:2000 certified and conform to IPC-A600(PCB) and IPC-A610 (PCB Assembly) standards. All our PCB/PCBA are UL certified and RoHS compliant.
Our Principle is simple, “Act by heart, Make the best.”
Our strength is distinct, “Years of experiences in PCB and PCBA field”
Our Goal is achievable, “ To be the most reliable supplier of PCB and PCBA.”
Our orientation is clear, “Focus on prototypes and low to medium volume business ”
