China led bulb pcb manufacturer with professional engineer
| UL Cert. | Y |
| ISO Cert. | ISO9001 :2008 |
| TS16949 | Y |
| ISO14000 | Y |
| Mode of Production:SMT&DIP | Metal Coating:Copper |
Certification:RoHS, ISO, SGS |
Base Material:FR-4 |
Condition:New |
Customized:Customized |
Specification:Shenzhen Rigao PCBA |
Package:Vacuum Packing and Standard Carton |
Origin:Shenzhen, Guangdong |
Trademark:Rigao PCBA |
Production Capacity:60000PCS/Year |
led bulb pcb manufacturer
Shenzhen Rigao Electronics Co., Ltd is an experienced PCB and PCBA manufacturer in Shenzhen, China. After several years' developing and improving, our company establishes our main business in three principal areas-Printed Circuit Boards, PCB Assembly and Components Procurement. From prototype to mass production, we are able to guarantee a complete service with technical back up, offering a cost advantage and continuity of supply.
For making PCBA, customers just need to provide us with Gerber file and bill of material. Components procurement is one of the featured services we can provide. IC, battery, fuse, LCD, transformer, LED Diode, connector, sensor, we could purchase all these electronic parts to our customers.
Our PCBA capability and services: SMT/THT/DIP.
1. Component Purchasing Service
2. SMT assembly and through hole components insertion
3. IC pre-programming / Burning on-line
4. Function testing as requested
5. Complete Unit assembly (which including plastics, metal box, Coil, cable inside etc)
6. Packing design
PCB/PCBA Description:
1. Single sided PCB, double sided PCB & multilayer PCB with competitive price, good quality and excellent service.
2. FR-4, FR-4 High TG, CEM-1, CEM-3, Aluminum base material.
3. HAL, HAL lead free, Immersion Gold/ Silver/Tin, OSP surface treatment.
4. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
5. Quantities range from prototype to medium and batch production.
Please tell us the information as below:
NO. |
Items |
NO. |
Items |
1 |
Board for what product |
8 |
Surface Finish |
2 |
Number of Layers |
9 |
Board Material |
3 |
Copper Thickness(um) |
10 |
Board Thickness(um) |
4 |
Solder Mask Color |
11 |
PCB Dimensions(mm) |
5 |
Silk Screen Color |
12 |
Min Finished Hole Size(mm) |
6 |
Milling |
13 |
Min Clearance(mm) |
7 |
Min Track Width(mm) |
14 |
Other special requirements |
PCB Fast delivery:
Packaging |
Vacuum Packing with desiccant, |
||
|
|
Prototype |
Mass production |
2L |
Quick turn:24h |
5-10days |
|
4L |
Quick turn:48 hours; |
8-15days |
|
6L |
Quick turn:72 hours; |
10-16days |
|
8L |
Quick turn:72 hours; |
16-18days |
|
10L |
Quick turn:96 hours; |
18-20days |
|
`` |
`` |
`` |
Our PCB process capability
PCB Description |
Our PCB Board Capability |
PCB Surface Finishes |
electrolytic nickel-gold, |
PCB Max. Size |
1200mm×600mm |
PCB Min. Size |
5mm×5 mm |
Bow & Twist Tolerance |
Single Side≤1.0%,Double Side≤0.7%, Muti-Layer≤0.5% |
Min. Board Thickness & Tolerance |
0.2mm±0.08mm |
PCB Min. trace/spacing |
Tin board:0.2mm±20%(8mil±0%) |
gold board: |
0.075mm±20%(3mil±0%) |
Copper to Board Edge Spacing |
0.5mm(20mil) |
Hole to Trace Spacing |
0.3mm(12mil) |
Min. Hole Diameter |
0.2mm±.076mm(8mil±3mil) |
Min. Hole Clearance |
0.4mm±.076mm(16mil±3mil) |
Copper Thickness on Hole Wall |
20-25um(0.79mil-1.0mil) |
Hole Location Tolerance |
±0.076mm(l±3mil) |
Min Diameter of Punching Hole |
FR-4 board thickness≤1.0mm(40mil):1.0mm(40mil) |
FR-4 board thickness 1.2-3.0mm(48-120mil):1.5mm(60mil) |
|
PCB Min. Punching Slot |
FR-4 CEM-3 board thickness≤1. 0mm(40mil):0.8 mm×0.8 mm(32mil×32mil) |
FR-4 board thickness1.2-3.0mm(48-120mil): 1.0 mm×1.0 mm(40mil×40mil) |
|
Trace width variation |
±0.076mm(±3mil) |
Outline Tolerance |
Routing:±0.1mm (±4mil) ,Punching:±0.05mm (±2mil) |
V-CUT Registration Tolerance±0.2mm (±8mil) |
|
PCB BOARD Type |
Single-sided, double-sided, multi-layer |
Major Material |
FR-4, CEM-1,CEM-3, high frequency laminates, Aluminum, NiFe-based, copper base |
PCB BOARD Thickness |
0.2-3.5mm |
Base Copper Thickness |
11um 35um 70um 105um |
Max. aspect ratio(board thickness: hole size) |
8:1 |
V-Cut Angle Tolerance |
±5° |
V-Cut Board Thickness |
0.4mm -3.2mm(16mil -128mil) |
Min SMT Pitch |
0.3mm(12mil) |
Min. Component mark |
0.15mm(6mil) |
Min. width of annular ring(finished) |
0.15mm(6mil)/side |
Min pad opening |
0.076mm(3mil) |
Min S/M Bridge |
±0.076mm(±3mil) |
carbon ink board manufacturing capability: |
1.Impedance Control:20K±10% 2.Hardness:6H 3.bearable friction times :above 200000 times |
Q: What is your MOQ?
A: We accept any quantity you want to order, prototype and mass production both are welcome.
Q: What do you need for quotation?
A: We need six informations from you as following show:
- Material:
- Board Thickness:
- Copper Thickness:
- Surface treatment:
- Gerber rle or other PCB data hle:
- Quantity:
For PCB assembly, we need BOM of components.
Q: Can you provide reverse engineering?
A: Yes, we do this service and we call it PCB or PCBA clone/copy,we just need the sample from you.
Q: Do you have your owr products?
A: No, we just do the customized PCB and PCBA prodution, also PCB/PCBA design is welcome.
