Home > Industrial Equipment & Components > Cutter & Tongs > Milling Cutter > DIN845 HSS Morse Taper End Mill
US$ 1.2 - 80
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
TONGYU
Model Number:
TY10-18.2.1.1
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DIN1837 HSS Metal Slitting Saw BladesUS$ 1 - 80MOQ: 100 Pieces -
DIN844 Straight Shank 4 Flutes HSS End MillsUS$ 0.9 - 60MOQ: 500 Pieces
-
DIN1833 HSS Dovetail Milling CutterUS$ 2 - 50MOQ: 100 Pieces
-
Carbide or HSS Shell End Mill CutterNegotiableMOQ: 30 Perches
-
Solid Carbide Cylindrical Shank 2 Flutes End MillUS$ 1 - 17MOQ: 50 Pieces
Place of Origin
Jiangsu, China
Brand Name
TONGYU
Model Number
TY10-18.2.1.1
Material
High Speed Steel
Diameter
10MM-63MM
Type
End Mill
Coating
Other, Tin-coated/bright finishing
Specifications
Morse taper shank end mill1.Guaranteed hss raw material
2.With comparative price advantage
3.Customization is available
Specification:
| 1. Standard: | DIN845-N (GOST standard is also available) |
| 2. Material: | HSS 4341(W4Mo3Cr4V), 6542(W6Mo5Cr4V2) |
| M35 (W6Mo5Cr4V2Co5), M42 (W6Mo5Cr4V2Co8) | |
| 3. Hardness: | HSS4341:HRC63-64, HSS 6542:64-65, HSS M35:HRC 66-67 HSS M42:HRC 67-68 |
4. Surface finishing: | Bright finishing;Tin-coated; or customization |
| 5.Application: | Suitable for milling lateral face, end face, flute and step face. Also for two vertical planes and form plane. To passing core end edgeend mill, also used for drilling and insertion milling. In structural steels with resistance 1200 N/mm². |
6. Size:
| D (MM) | L (MM) | l (MM) | Z | KM |
| 10 | 92 | 22 | 4 | 1 |
| 11 | 92 | 22 | 4 | 1 |
| 12 | 96 | 22 | 4 | 1 |
| 14 | 111 | 26 | 4 | 2 |
| 16 | 117 | 32 | 4 | 2 |
| 18 | 117 | 32 | 4 | 2 |
| 20 | 123 | 38 | 4 | 2 |
| 22 | 123 | 38 | 4 | 3 |
| 25 | 147 | 45 | 4 | 3 |
| 28 | 147 | 45 | 4 | 3 |
| 30 | 155 | 53 | 6 | 3 |
| 32 | 178 | 53 | 6 | 3 |
| 36 | 178 | 53 | 6 | 4 |
| 40 | 188 | 63 | 6 | 4 |
| 45 | 188 | 63 | 6 | 4 |
| 50 | 233 | 75 | 6 | 5 |
| 56 | 233 | 75 | 6 | 5 |
| 63 | 248 | 90 | 6 | 5 |
In addition, the quality of HSS tools are basically decided by HSS raw material and heat treatment.
We can keep a strict control of these procedure.
Package:
Exporting outer carton, then in pallet.
Pls. contact us freely for more information, I will reply you ASAP!
Hope you will enjoy a comfortable cooperation with us!
