High Quality Roof Tile Roll Forming Machine
Features & Purposes:
This roof tile roll forming machine is comprised of mechanic decoiler, feeding equipment, pre-punching hydraulic device, roll forming unit, post hydraulic mould cutting device, hydraulic station, PLC control system and unloading rack.
We can supply the machine producing any profile tile!
Production processing :
Decoiling---forming---cutting-to-length---collecting
Equipment struction introduction:
Color Steel Ridge Tile Roofing Cold Roll Forming Machine , Metal Ridge Cap Roll Former is the special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, decoiling the coil, continuous rolling and cold-forming, automatically cut to the size and output the finished panel. The equipment adopts PLC control, AC frequency and adjusting the speed technology, and it realizes the continuous automatically production, therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.
1 |
Suitable material | color steel roof tile |
| 2 | Main motor power | 5 KW with Cycloidal reducer |
| 3 | Hydraulic station power | 4KW |
| 4 | Hydraulic oil | 46# |
| 6 | Thickness | 0.35-0.65 |
| 7 | Diameter | Φ70mm |
| 8 | Electric tension | 380V 3phase 50HZ |
| 9 | Material of roller | High grade 45# forged steel |
| 10 | Rolling galvanization thickness | 0.05mm |
| 11 | Processing speed | 10-15m/min |
| 12 | Processing precision within | 10m+/-1.00mm |
| 13 | Material of cutting blade | Cr12 quenched |
Roof tile profiles:
HIgh exported quality roof tile making mahine $14,500
Cost performance quality roof tile machine :$ 9500USD
Used for roof tile :
My workshop and loading for customer
1:How to play order: Inquiry---confirm the profile drawings and price----confirm the PI---arrange the doposit or L/C---then OK
2:How to visit our company:
Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours),then we can pick up you.
If any questions,you can call me mobile phone at any times:0086-13091161261
3:If you want to get more pictures or videos of the machines,I can send them to you by Email or SKype.
we are capable of designing machine totally as your panel sample and profile drawing
please no hesitate to contact us.
warmly welcome to visit our factory and order machine, we promise to provide you machine with best quality!
Contact: 0086-13091161261
