Help CenterTRUNK CATV BOOSTER/CATV LINE AMPLIFIER
Related Products
-
Professional Catv Amplifier Power SupplyUS$ 0.1 - 5MOQ: 200 Pieces -
Professional Catv Amplifier Made in ChinaUS$ 0.1 - 5MOQ: 200 Pieces
-
CATV Distribution Trunk Amplifier Made in ChinaUS$ 0.1 - 5MOQ: 200 Pieces
-
Trunk Line CATV Signal AmplifierUS$ 0.1 - 5MOQ: 200 Pieces
-
1GHz CATV Line Extender Outdoor Trunk AmplifierUS$ 0.1 - 5MOQ: 200 Pieces
Frequency Range |
47(85)-750(862)MHz |
||||
Nominal Gain |
22dB |
26dB |
30dB |
33dB |
35dB |
Nominal Output Level |
94dBuV |
98dBuV |
102dBuV |
102/105/99dBuV (750/862)/550/47MHz |
104/107/101dBuV (750/862)/550/47MHz |
CXM (PAL-D59ch) |
82 |
74 |
68 |
68 |
64 |
CTB (PAL-D59ch) |
82 |
75 |
68 |
68 |
64 |
CSO (PAL-D59ch) |
68 |
66 |
64 |
64 |
62 |
Bandwidth |
45-860Mz |
||||
Gain&Input Level Adjustable Range |
0- -10dB |
||||
Flatness |
±0.75dB |
||||
NF |
<10dB |
||||
Power Consumption |
19W |
||||
Return Loss |
≥16dB(47-550MHz), ≥14dB(550-750/862MHz) |
||||
Group Delay |
t<10ns(57.75MHz, 62.18MHz, 47-550MHz) t<10ns(112.25MHz, 116.68MHz, 85-550MHz) |
||||
HUM Modulation |
≥66dB |
||||
Surge |
≥5KV(10/700ns) |
||||
Supply Voltage |
YTF51: 135-270Vac YTF52: 35-70Vac |
||||
1. Your inquiry will be replied within 24 hours.
2. Our delivery time is 15 days, we will contact if there are special circumstances.
3. OEM&ODM.
4. We can do the product from your drawing, sample or indicated details.
A:Do you only have these types of products ?
XT: No, We can do other products just need to give us your product samples and data.
B :How about your product quality and piece?
XT: We have different material products, you can choose according to your needs.
C :I dont know if your product is suitable for us.
XT: Dont worry,we can give our samples to you if you need.
