10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector

10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector thumbnail-1
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector thumbnail-2
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector thumbnail-3
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector thumbnail-4
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector thumbnail-5
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector photo-1
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector photo-2
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector photo-3
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector photo-4
10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector photo-5
US$ 20 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DONGWE
Model Number:
DW-MCD231-02T
Contact Supplier Request Quote Chat Now
Shenzhen Dongwe Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DONGWE
Model Number DW-MCD231-02T



   10/100M, 2-RJ45 Ports Media Converter, 2km, SC/ST/FC Connector

Product Description

 Features

  • 2-RJ45 Ports Media Converter
  • 1 x 100BaseFX optical fiber Ethernet port
  • Ideal for non-stop industrial communications
  • DW-MCX2XX-XXT Unmanaged Redundant Ethernet Switch has one optical fiber Ethernet port. Its highly reliable hardware design is ideal for non-stop industrial applications.

Specifications

Standards:

  • IEEE 802.3
  • IEEE 802.3u

Interfaces:

  • DW-MCX2XX-XXT: 1 x 10/100BaseFX port + 2 x 10/100BaseTX ports
  • RJ-45: 10/100BaseTX
  • Console: RS-232 (RJ-45 connector)

Power Supply:

  • Input Voltage: 24VDC (12 ~ 36VDC)
  • Input Current:
  • IDS 403-1F: <0.1A@24VDC
  • Overcurrent protection: provided
  • Short circuit protection: provided
  • Connector: 3-pin connector

Mechanical:

  • Case: metal with IP40 protection
  • Dimensions: 32x78x103 mm
  • Weight: 260g
  • Installation: rack mount or wall mount

Environment



Operating temperature:

  • Extended: -40 ~ +75°C (-40 ~ 167°F )
  • Storage: -40 ~ +85°C (-40 ~ 185°F)
  • Humidity:5 ~ 95% (non-condensing)



Standards and Certifications:

  • Safety: UL 60950-1
  • EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
  • EMS:
  • EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3,
  • EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3,
  • EN 61000-4-6 (CS) Level 3,EN 61000-4-8 Level 3
  • Shock: IEC 60068-2-27
  • Free fall: IEC 60068-2-32
  • Vibration: IEC 60068-2-6
  • Warranty: 5 years

 Dimensions

Ordering Information

    Part Number                                     Description
  DW-MCD231-02T   10/100M,2*RJ45,dual fiber,2km,SC/ST/FC connector,-40 ~ +75°C
  DW-MCD231-20T   10/100M,2*RJ45,dual fiber,20km,SC/ST/FC connector,-40 ~ +75°C
  DW-MCD255-40T   10/100M,2*RJ45,dual fiber,40km,SC/ST/FC connector,-40 ~ +75°C
  DW-MCD255-80T   10/100M,2*RJ45,dual fiber,80km,SC/ST/FC connector,-40 ~ +75°C
  DW-MCD255-12T   10/100M,2*RJ45,dual fiber,120km,SC/ST/FC connector,-40 ~ +75°C




  DW-MCS235-20T
  DW-MCS253-20T

   10/100M,2*RJ45,Single fiber,20km,SC/ST/FC connector, -40 ~ +75°C


  DW-MCS235-40T
  DW-MCS253-40T

   10/100M,2*RJ45,Single fiber,40km,SC/ST/FC connector, -40 ~ +75°C


  DW-MCS235-60T
  DW-MCS253-60T

   10/100M,2*RJ45,Single fiber,60km,SC/ST/FC connector, -40 ~ +75°C


  DW-MCS245-80T
  DW-MCS254-80T

   10/100M,2*RJ45,Single fiber,80km,SC/ST/FC connector, -40 ~ +75°C


  DW-MCS245-10T
  DW-MCS254-10T

   10/100M,2*RJ45,Single fiber,100km,SC/ST/FC connector, -40 ~ +75°C
