Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Hipower | Model Number: | SC12.0WX |
Power Source: | Electric | Application: | Auto | Capacity: | 12000lb (5443kg) single line |
Product Description
4WD Synthetic rope winch 12000lbs, Nylon rope winch
We are professional factory for 5000Lb-13000Lb winch and winch accessories.
1. Specification:
for 12000lb winch:
Rated line pull | 12000lb (5443kg) single line |
Motor | 6.6hp/4.85kw, series wound |
Control | remote switch, 12ft(3.7m) lead |
Gear train | 3 stage planetary |
Gear reduciton ratio | 191:1 |
Clutch | keyway cam clutch |
Braking | automatic load-holding brake |
Drum size | Ø2.5″*L8.8″ (Ø63.5mm*L224mm) |
Synthetic rope | Ø10mm*28m |
Fairlead | 4-way roller fairlead |
Wirelesss Remote control | optional |
Battery leads | 2 gauge,72"(1.83m) |
Finishing | black, dark grey coating |
Overall dimension | 538*160*214mm |
Mounting bolt pattern | 254*114.3mm |
N.W/G.W. | 26/28KG |
Packing | foam package, 1pc/ctn |
Battery recommended | 650CCA minimum for winching |
2. Outstanding Features:
1. Series wound motor, high 6.6 hp motor, delivers plenty of power.
2. Gears are made of 20Cr steel, crafted with cold extrusion and heat treatment, for toughest pulling demand.
3. New key way cam clutch with ratio 191:1, or common Sliding ring gear 230.4:1;
4. sealed winch and solenoid
5. We have 100% testing on winch pulling capacity and function.
6. Safe packages-foam and/or pallet
7. Warranty 18 months, CE approved
Foam and carton for 1 piece, 20, or 30 in one pallet.
3. Packing:
We also have recovery accessories.
3. Company introduction:
We are a professional electric winch manufacture in Ningbo, China. Our winch line includes: ATV winch 2000lb-3000lb, electric winch 5000LB-13000lb and winch accessories. We have strict quality control, insisting tests on pulling and function for every single winch before delivery. We have experienced engineers and sales for your OEM requests.
Over the past 3 yers, we have exported to America, Austria, Canada, France,Germany, Kenya, Russian, Uruguay and other countries world wide. Feedbacks have been quite good. Pls contact us for further questions.
