Specifications
casting or steel parts rotary table shot blasting cleaning machineLong life time
Good quality
Company indroduction:
Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..
Products Detail:
Q35 seies casting or steel parts rotary table shot blasting cleaning machine:
Q35 turntable Shot Blast machines are the ideal choice for blast cleaning; automotive parts and engine components, petroleum valves and compressors, castings , fabrications and weldments and numerous other items that are not suitable for tumbling due to size and shape. Parts to be cleaned are rotated on the table exposing the parts or castings to the abrasive blast. All tables are covered with abrasive resistant liners for superior wear. Q35 Table Blast machines are offered in various configurations with blast wheels mounted on the side, hip and top of the machine. Some models offer oscillating blast wheels to allow more thorough blast pattern coverage.
Main technical parameters of Q35 series:
Models |
Q3512 |
QF3512 |
QF3525E |
||
Dimension of cleaning chamber |
mm |
Φ1350×560 |
Φ1350×860 |
Φ2654×560 |
|
cleaning workpieces size |
mm |
600×250×250 |
600×250×500 |
600×500×250 |
|
Turntable car |
Loading |
kg |
400 |
400 |
1000 |
weight |
mm |
Φ1200 |
Φ1200 |
Φ2500 |
|
Blasting wheel |
Blasting capacity |
kg/min |
200 |
2×120 |
2×250 |
power |
kw |
11 |
7.5×2 |
15×2 |
|
Lifting capacity of Elevator |
t/h |
15 |
15 |
30 |
|
Separation quantity of separator |
t/h |
15 |
15 |
30 |
|
first Loading quantity of shot |
kg |
400 |
400 |
1500 |
|
Ventilation volume |
m3/h |
2800 |
2800 |
5200 |
|
External dimension |
mm |
1500×3450×3780 |
1900×1900×4165 |
4260×3647×5366 |
|
Power (except for dust cleaning) |
kw |
24.5 |
24.5 |
35.2 |
|
Casting or steel parts rotary table shot blasting cleaning machine picture:
