Specifications
1.OEM2.Suitable for ship, automobile and rolling stock do surface derusting.
3.for bridge and machinery and etc.
4. ISO9001
Specifications:
Serial number |
Type Item |
Q698 |
Q6912 |
Q6915 |
Q6920 |
Q6925 |
Q6930 |
Q6940 |
|
1 |
Effective cleaning width |
mm |
800 |
1200 |
1500 |
2000 |
2500 |
3000 |
4000 |
2 |
Inlet opening dimension |
mm |
800*1600 |
1200*400 |
1500*400 |
2000*400 |
2500*800 |
3000*800 |
4000*400 |
3 |
Length of cleaning piece |
mm |
1200--12000 |
1200--6000 |
1200--12000 |
1200*12000 |
3000--12000 |
2400--12000 |
4500--18000 |
4 |
Roller speed (Stepless speed reulation) |
m/min |
0.5--4 |
0.5--4 |
0.5--5 |
0.5--4 |
0.5—4.5 |
0.5--4 |
2—8 |
5 |
Thickness of cleaning steel plate |
mm |
3--60 |
3--60 |
1.5--60 |
3--60 |
3--60 |
3--110 |
4.5--100 |
6 |
Treated section bars specification |
|
Diameter:: 16--28 |
[<=20#<<=16# |
[<=20#<<=16# |
[<=20#<<=16# |
|
60*8—300*1000 |
|
7 |
Blasting capacity |
Kg/min |
8*120 |
4*250 |
4*250 |
6*250 |
6*250 |
6*360 |
8*360 |
8 |
First charge weight |
kg |
4000 |
4000 |
4000 |
4500 |
4500 |
8000 |
11000 |
9 |
Adjusting height of rolling brush |
mm |
4000 |
200 |
350 |
450 |
600 |
850 |
900 |
10 |
Ventilation capacity |
M3/h |
22000 |
17560 |
19000 |
19550 |
27758 |
28050 |
38000 |
11 |
Outline dimensions |
mm |
25017*4250 *9015 |
12180*4250*7095 |
15200*5370 *6797 |
30650*6850*9095 |
31200*6850*9095 |
44042*6385*7758 |
45000*7830*11117 |
12 |
Pit depth |
mm |
1937 |
1616 |
2257 |
2800 |
2353 |
2800 |
4370 |
13 |
Total power (Excluding dedusting) |
kw |
90 |
78.3 |
113.5 |
156.6 |
224.55 |
204.8 |
293.6 |
