hot sale stainless steel exterior aluminum composite panel / PE/PVDF ACP/ACM For Building/Decoration

1.Specifications

2.Quality

    1)Under natural climate ,film coating will be no flake .no rubbles ,no vestige and no pulverization.

    2)Under common environment.no flake.no rubbles.

    3)Under common temperatures and radiation,no color deferent.

    4)According to international test standard,all the tested items are satisfied with high-class.

    5)Our products with PVDFcoating which produced under GB/T17748-1999 is with 70% PVDF.and under common environment,  we canguarantee 15~20 years;and for FR products,it is good at fireproof,and the FR grade is B1(according to the standardQB862

3.Seaworthy packing

   1) 20 foot container: 2mm panel-6000M2, 3mm panel-5000M2, 4mm panel-4000M2, 5mm panel-3000M2.

   2) 40 foot container:2mm panel-8000M2,  3mm panel-7000M2,  4mm panel-6000M2, 5mm panel-5000M2.

4.Material

  1) Top: aluminum alloy(3003) coated with Fluorin carbon resin (PVDF) or Polyester resin  (PE) roasting painting.

  2) Core:non-toxic polyethylene or  fireproof material(B1).

  3) Back:aluminium alloy sheet coated with polyester resin painting.

  4) Surface finish: PVDF / PET coated,brushed finish, mirror finish, wooden faced,marble faceed ,nano paintingect.

  5) Surface coating thickness :25~30 μm  70% KYNAR 500 PVDF or PET.

5.Feature

  1)Super werther resistance

  2)Light weight easy to process

  3)Excellent fire resistance

  4)Excellent impact strength

  5)Uniform and colorful coating

  6)Easy maintenance...and so on

6.Certification

   According to GB/T17748-1999 standard and ISO9001,SGS,CE etc.

7.MOQ

    MOQ:1000 SQM , Stock size could be less .

8.Delivery time

    Within 15 work days after receiving the first deposite payment .

9. Payment

    T/T, L/C

10.Production capacity

Average 3500 SQM/Day

Interior/exterior PE/PVDF ACP/ACM aluminum sandwich panel aluminium composite panel for wall decoration

For the further questions feel free to contact me .

Jerry

Phone & whatsupp & Wechat: +86-18264928599

Skype & email : aluroofing(at)

3mm,4mm Glossy/mirror/ marble/ Wooden Texture Interior/exterior PE/PVDF ACP/ACM aluminum sandwich panel aluminium composite panel for wall decoration

 *Products and workshop show

PVDF Aluminum Composite Panel:

By adopting PVDF paints from the two toppest paint supplier: American PPG and Sweden Beckers, Megabond® PVDF Aluminum Composite Panel is the most ideal material for facade cladding, curtain wall cladding and other outdoor using purpose.

PVDF is short for Polyvinlylidene Fluoride, the color will have no obvious change within 15 to 20 years when it’s applied outdoor. PVDF paint should be 2-layer coating or 3-layer coating, and Painting Thickness ≥25um., Fluorocarbon Powder ≥70%.

Polyester(PE) Aluminum Composite Panel:

Due to Polyester paints’s great nature, it can achieve versatile vivid color and achive higher gloss rate than PVDF. Megabond® Polyester Aluminum Composite Panel is ideal for interior wall and shopfront decoration and signaboard materials.  And it can lower your budget the most.

With Polyester, the color has 5 to 10 years color warranty. Painting Thickness ≥18um, usually its a 1-layer coating or 2-layer coating.
